FPV Drone Control Transmitter Antenna (380 - 440 MHz) Aeronetix

Brand: Aeronetix. This specialized antenna is designed for FPV drone control and stable radio communication in the 380 - 440 MHz operating range. It combines moderate gain, convenient dimensions, and compatibility with standard SMA connectors, making it versatile for mounting on the aircraft chassis or within the transmitter housing.

Description and Advantages

The antenna provides improved coverage in the 380 - 440 MHz range with 5-6 dBi gain, increasing signal range and reliability for control command transmission. The 90° / 120° beamwidths allow choosing a balance between narrow directivity for long-range connections and wider coverage for maneuvering. Compact dimensions with cable 265 × 155 × 10 mm and a low weight of 52 g minimize impact on platform aerodynamics, while the 40 mm cable length allows for compact antenna connection without undue strain on the mount. The antenna is intended for use in FPV and radio communication systems where stable drone control and reliable command transmission in the VHF/UHF frequency range are required.

Technical Specifications

• Frequency Range: 380 - 440 MHz
• Gain: 5-6 dBi
• Beamwidth: 90° / 120°
• Dimensions (with cable): 265 × 155 × 10 mm
• Cable Length: 40 mm
• Connector: SMA
• Weight: 52 g

Below is a complete list of parameters and additional dimensions contained in the original product data:

The antenna is compatible with equipment supporting an SMA connector; the short 40 mm cable allows for compact connection to the transmitter without undue strain on the mount. With 5-6 dBi gain and the option to choose between 90° and 120° beamwidths, it is optimal for applications requiring a balance between range and coverage, such as controlling FPV drones at medium and short distances. The lightweight body (52 g) and small dimensions with cable 265 × 155 × 10 mm ensure easy mounting on various platforms without significant impact on weight and aerodynamics.

We recommend checking the antenna's compatibility with your transmitter and the presence of an SMA connector before installation. If a different antenna placement or a longer cable is needed, please contact our consultants to select the optimal solution from Aeronetix products or compatible alternatives. The specified additional attributes (Length 25.0; Weight 0.100 kg; Height 1.0; Width 16.0) will help better plan mounting and packaging for delivery.
