FPV Drone Control Transmitter Antenna (480 - 520 MHz) Aeronetix
Brand: Aeronetix. This antenna is designed for transmitting control signals for FPV drones and other radio equipment in the 480–520 MHz range, ensuring reliable communication over medium distances and stable operation in flight. It combines a compact design with optimized parameters, making it convenient for integration into various transmitter housings or onto the frame of the device.
Specifications
- Frequency Range: 480–520 MHz
- Gain: 5–6 dBi
- Beamwidth: 90° / 120°
- Dimensions (with cable): 204 × 120 × 10 mm
- Cable Length: 80 mm
- Connector: SMA
- Weight (per technical description): 24 g
The antenna provides a balance between signal directionality and coverage width thanks to its 5–6 dBi gain and two beamwidth options (90° and 120°). This is important for stable control during FPV flight maneuvers and for reducing interference in urban or rugged terrain. The lightweight and compact design facilitates mounting and allows the antenna to be used in both amateur and semi-professional setups.
In addition to the basic specifications, the additional parameters include physical dimensions and weight, which will help assess the antenna's compatibility with your equipment: Length: 17.0, Height: 5.0, Width: 13.0, Weight, kg: 0.100. This data is important when planning antenna placement in confined spaces or calculating the total weight of the platform.
The antenna features a standard SMA connector, ensuring simple and reliable connection to most transmitters and modules. The dimensions of 204×120×10 mm account for the connected 80 mm cable, and the 24 g weight makes the antenna a lightweight option for light platforms and booster mounts. Before purchasing, we recommend checking connector compatibility and physical mounting space dimensions for optimal integration.
| Parameter | Value |
|---|---|
| Length | 17.0 |
| Height | 5.0 |
| Width | 13.0 |
| Weight (kg) | 0.100 |
This versatile solution is suitable for FPV flight applications, repeaters, and stationary transmission points within the specified frequency range. If you need an antenna with moderate directionality and wide coverage for stable drone control, the Aeronetix model with a 480–520 MHz range and SMA connector will be an optimal choice. Also, check the beamwidth and physical dimensions for compatibility with your equipment before mounting.
