Microstrip Coplanar Antenna in Enclosure 750-6000 MHz — AB-Antennas

The professional AB-Antennas microstrip coplanar antenna, housed in a durable enclosure, provides stable communication across a wide frequency range from 750 to 6000 MHz. This product is designed for compact and portable applications, particularly for use on drones, where size and reliable reception/transmission are critical.

Description and Purpose

The antenna is intended for use in portable communication systems and on unmanned platforms. It features small dimensions of 120x15 mm and low weight, making it ideal for installation on drones and other mobile devices. Manufacturer brand: AB-Antennas. Product type: Antennas > Dipole Antennas.

Technical Specifications

• Antenna Type: Microstrip coplanar antenna
• Frequency Range (VSWR): 741...1560 MHz / 3159...4270 MHz / 5100...6006 MHz (VSWR < 2)
• Gain: 2 dBi
• Radiation Pattern: Omnidirectional
• Polarization: Vertical/Horizontal
• Dimensions: 120x15 mm
• Input Impedance: 50 Ohm
• Connector: SMA female / IPX
• Purpose: Antenna for portable applications, including drones

The antenna has a standard input impedance of 50 Ohm, ensuring compatibility with most wireless communication transmitters and receivers. The presence of SMA female and IPX connectors allows for easy connection to various equipment and adapters.

Advantages of Choice

• Wide operating range of 750–6000 MHz for multi-spectrum operation.
• Compact dimensions of 120x15 mm — optimal for mounting on drones and portable devices.
• Low gain of 2 dBi ensures stable reception without unnecessary system complexity.
• Universal polarization (vertical/horizontal) increases flexibility in system setup.
• Low VSWR (SWR < 2) in the specified bands guarantees efficient antenna operation.

This AB-Antennas microstrip coplanar antenna will be a reliable component in communication systems for unmanned aerial vehicles and portable equipment. It combines compactness, a wide frequency range, and standard connection interfaces.
