4.9GHz/1.2GHz Repeater for Matrice 30/300 by SkyReach

SkyReach offers a high-performance repeater for DJI Matrice 30 and DJI Matrice 300 drones, designed to extend communication range and ensure reliable video signal reception. The device is optimized for operation in challenging conditions and can be modified to meet customer requirements. The repeater provides simultaneous video reception in the 4.9–5.8GHz range and video signal transmission to the operator at 1.2GHz, guaranteeing stability and minimal latency in image transmission.

Key advantages: extensive customization options for control ranges (433–2800MHz, customer's choice), support for popular ELRS and TBS TX modules, powerful video reception antennas (SI 5.8GHz 19.5dBi patch and Helix 27 turns 18dBi), and compact power from a single 2S 21700 battery with an XT30 connector. The device operates for up to 2 hours on a single charge, allowing for extended missions without frequent battery replacements.

Purpose

The repeater is designed for use as a ground signal relay station for DJI Matrice 30 and Matrice 300 UAV systems (compatibility to be confirmed upon order). Ideal for search and rescue operations, long-range aerial photography, inspection tasks, and missions where range and video communication quality are critical.

The repeater features a well-thought-out design for quick installation and module replacement. The package includes everything needed for quick setup and integration with the platform: repeater, video reception antennas, supported TX modules, 2S 21700 battery, and mounting adapter. Installation is performed with four included screws, ensuring secure attachment to the chassis or a special bracket.

Pre-order and custom settings: customization of control ranges and antenna types for specific customer tasks is possible. When placing an order, specify drone model compatibility and desired TX module parameters.
