DongFeng DF-404 G2 Mini Tractor with Cabin — Reliability and Comfort in Any Weather

Manufacturer: DongFeng. Category: Tractors > Mini Tractors. The DongFeng DF-404 G2 mini tractor in the cabin version combines power, robust construction, and operator comfort. The cabin protects against rain, snow, and scorching sun and is equipped with a ventilation system for working in dusty conditions. The model is ideal for private farms and small businesses due to its optimal combination of price, quality, and functionality.

Engine: ZN490BT — diesel, vertical, 4-cylinder with liquid forced cooling system and direct injection, nominal power 40 hp (29.4 kW). Engine displacement — 2543 cm³, cylinder bore/piston stroke — 90 × 100 mm, nominal crankshaft speed — 2400 rpm. Starting is performed by an electric starter with safe start. The cooling system has a volume of 12 L, fan drive — V-belt transmission, ensuring reliable protection against overheating under intense loads.

Operating costs: nominal fuel consumption ≤ 255 g/kWh, nominal engine oil consumption ≤ 2.04 g/kWh. Fuel pump type — plunger in-line. Fuel tank capacity is 28 L.

Transmission and chassis: 4 × 4 drive, gearbox (4 + 4) x 2 with reverse, rear differential lock available, dry, dual-disc clutch. Power steering ensures ease of control, braking mechanism — drum type. Power take-off (PTO) shaft speed: 540/720 rpm. Hydraulic system pump type — gear pump; maximum lifting capacity of the three-point hitch — 665 kg.

Dimensions and wheels: wheelbase 1818 mm, minimum ground clearance 378 mm. Wheel track: rear 1100 (base); 1200; 1300; 1400 mm, front 1200 mm. Tire size: rear 7.5 × 16, front 12.4 × 24. Minimum turning radius with one-sided braking — 3.2 m. Theoretical travel speed: forward 1.75–32.2 km/h, reverse 2.3–11.92 km/h. Overall dimensions (L × W × H): 3354 × 1500 × 2300 mm. Structural weight — 1685 kg.

Application: The DongFeng DF-404 G2 model is suitable for a wide range of tasks — soil cultivation with various attachments, cargo transportation, work with trailed equipment. A reliable diesel engine and efficient cooling system increase equipment lifespan and ensure long-term trouble-free operation.

Purchase options: orders can be placed via the website or by phone, with short delivery times. A credit purchase option is also available through a partner bank — to clarify terms, leave your number in the feedback form or contact a manager.

Key advantages:

• 40 hp (29.4 kW) power and durable ZN490BT diesel engine;
• Cabin with ventilation for comfortable and safe work in any weather;
• 4×4 all-wheel drive, reversible gearbox, and rear differential lock for maneuverability and work on difficult terrain;
• Power steering and dual-disc dry clutch for convenient control;
• Versatility of attachments and lifting capacity of 665 kg.

Technical specifications:

Summary: The DongFeng DF-404 G2 with cabin is a practical choice for field and farm work where 40 hp power, versatility of attachments, operator protection, and the ability to work in various climatic conditions are important. For purchase or consultation, please contact the store manager.
