EW Wartex Mamai LOW FPV 100W — Powerful Trench Jamming System

EW Wartex Mamai LOW FPV 100W from manufacturer Wartex is a professional electronic warfare device specifically designed for reliable suppression of FPV drone control and video transmission channels. The device combines a total output power of 100W (50W per channel) with compact dimensions and convenient operation, making it suitable for stationary use in trenches, as well as for mounting on armored vehicles or other equipment.

Key Advantages

Wartex Mamai LOW FPV 100W effectively jams the most common FPV protocols, including ELRS and TBS, both with standard settings and with shifted or lowered frequencies. The delivery package includes everything necessary for immediate deployment: antennas, battery, and charger, so no additional purchases are required. The robust and compact design allows for quick transportation and deployment of the device in field conditions.

Technical Specifications

• Operating ranges: 400–500 MHz and 500–600 MHz;
• Power: total 100W, 50W per channel;
• Power consumption: 280W;
• Power input: 12–28V;
• Power connection: XT60 connector;
• Antenna directivity: 360 degrees;
• Antenna type: collinear dome antennas, omnidirectional;
• Weight without battery: approximately 2.8 kg;
• Dimensions without antennas: 210×130×85 mm;
• Dimensions with antennas: 610×130×85 mm;
• Package contents: antennas, battery, charger included;
• Operating time: up to 90 minutes of continuous operation.

Antennas with 360° directivity and optimal placement ensure uniform coverage of the area around the carrier, allowing effective control of airspace and blocking FPV channels across a wide range of frequencies. Despite its compact size (210×130×85 mm without antennas, 610×130×85 mm with antennas) and relatively low weight (≈2.8 kg without battery), the device provides a high level of signal suppression.

Thanks to 50W output power per channel, Wartex Mamai LOW FPV 100W withstands attempts by drone operators to bypass EW systems by shifting or lowering frequencies. The device is suitable for combat, security, and special tasks where reliable control of unmanned aerial vehicles is required.

The portable kit from manufacturer Wartex is a ready-made solution for operational use: simple connection via XT60 connector, autonomous operation for up to 90 minutes, and a complete set of antennas, battery, and charger. This offers an optimal balance of weight, dimensions, and battery life for field operations.

Product category: EW Jammers > Trench Jammers.
