SKYNOVA Air Retranslator Double TX for Matrice platform
Package contents:
-
Video receiver: SKYZONE Steadyview X — receives signal from drone
-
Control receiver: ELRS 700-1000 MHz
-
Video transmitter: ReadyToSky 1.2/1.3 GHz, 2 W — transmits video to FPV goggles
-
Control transmitter: Happymodel ES900TX
-
Alternative transmitter: TBS Crossfire Micro — backup or parallel control line
Antennas:
-
SKYNOVA Yagi 10 dBi (adjustable frequency 300-2800 MHz), VSWR 1.2
-
Log-periodic antenna for FHSS 700-1000 MHz, designed for use with TBS Crossfire, VSWR 1.2
-
SKYNOVA Helix antenna 17 dBi, 4.9-5.9 GHz band, VSWR 1.2
-
SKYNOVA Helix antenna 13 dBi, 4.9-5.9 GHz band, VSWR 1.2
Power supply:
-
3p battery system (12.3 V) — ensures stable operation of the 2W transmitter
-
Optional: 2s3p modification possible for increased autonomy
-
Advantages of the solution:
-
✅ Double TX mode — ensures simultaneous operation of two channels
-
✅ FHSS in the 700-1000 MHz band (Crossfire with 8 dBi) together with an additional conditional 2.2-2.8 GHz channel provides an advantage in conditions of active enemy EW
-
✅ Low system weight — allows for increased flight duration
-
✅ IP55 standard protective case — waterproof, dustproof, and shockproof
-
✅ 12 months warranty + service maintenance, including replacement of damaged housing parts upon request (in case of damage during operation)
