The 12-meter portable telescopic mast "ЩТП-12-1" for antennas weighing up to 5 kg is an ideal solution for raising antennas to a significant height, which significantly improves the quality and stability of radio and television signal reception. Its telescopic design allows for easy and quick deployment of the mast to a maximum height of 12 meters, as well as compact folding for convenient transport and storage. Thanks to its versatility, the mast is suitable for installing various types of antennas weighing up to 5 kg.

The well-thought-out design of the ЩТП-12-1 mast ensures easy adjustment of the horizontal signal reception angle, quick deployment and installation even on uneven surfaces, and quick retraction after use. Made of high-quality steel with sandblasting and polymer coating, the mast is characterized by high rigidity, durability, and reliable protection against atmospheric influences and corrosion.

Key features of the ЩТП-12-1 portable telescopic mast

Advantages of using the ЩТП-12-1 telescopic mast

1. Increased signal reception: Raising the antenna to a height of up to 12 meters significantly improves the quality and stability of television and radio signal reception, reducing interference.


2. Easy adjustment: The design provides simple and quick adjustment of the horizontal signal reception angle thanks to the quick-release handle.


3. Versatility: The mast is suitable for installing various types of antennas weighing up to 5 kg.


4. Easy installation: Quick deployment and installation on uneven surfaces, as well as quick retraction of the mast, are ensured by the thoughtful design and telescopic legs.


5. Durability: Manufacturing from high-quality steel and reliable polymer coating ensure rigidity, long service life, and protection against corrosion.

Features of telescopic design and portability

The ЩТП-12-1 mast consists of seven telescopic sections of different diameters, which easily fit into each other and are fixed at the desired height with clamping fasteners. The first section is equipped with a base with telescopic legs and pointed tips for reliable fixation on various types of surfaces. The top section has a quick-release mechanism for convenient installation and replacement of equipment. To increase wind resistance, a ring is provided for installing guy wires on the fifth section.

Useful functions

• Raising antennas to a height of up to 12 meters to improve signal quality


• Easy change of horizontal signal reception angle using a quick-release handle


• Versatile use for various types of antennas weighing up to 5 kg


• Quick deployment and retraction of the mast


• Ability to install on uneven surfaces thanks to telescopic legs


• Additional fixation with guy wires to increase wind resistance


• Convenient cable routing thanks to open rings on each section

Compatibility with various antenna types

The ЩТП-12-1 portable telescopic mast is compatible with various types of antennas weighing up to 5 kg, including:

• Television antennas


• Radio antennas


• WiFi antennas


• Other lightweight communication antennas

ЩТП-12-1 portable telescopic mast package contents

1. ЩТП-12-1 telescopic mast - 1 pc.


2. Cover (bag) - 1 pc.


3. 7m guy wire - 3 pcs.


4. 10m guy wire - 3 pcs.


5. Quick-release handle - 1 pc.


6. Quick-release adapter for equipment - 1 pc.


7. Ground anchors - 3 pcs.


8. Technical passport - 1 pc.

Packaging

The mast and components are supplied in a special cover (bag) for convenient transport and storage.

If you need a reliable and portable mast for raising an antenna to a significant height, the ЩТП-12-1 portable telescopic mast will be an excellent choice. Its ease of use, versatility, and robust construction will provide an effective solution for improving signal reception in various conditions. We recommend purchasing this mast for your needs.
