1.2GHz/5.8GHz Repeater for Matrice 30/300 by SkyReach
The SkyReach wireless repeater for DJI Matrice 30 and DJI Matrice 300 drones is a professional solution for extending control range and ensuring reliable video signal transmission. The device allows selection between popular ELRS or TBS Crossfire TX modules for control in the 433 MHz – 2.8 GHz range, while simultaneously receiving video signals in the 1.08–1.36 GHz range and then transmitting video to the operator at 5800 MHz. The repeater is designed for mounting on standard DJI brackets using 4 screws (included) and is powered by a single 2S 21700 battery, providing up to 2 hours of operation on a single charge.
This device is ideal for professional applications where communication stability and high-quality video stream are critical: inspections, search and rescue operations, object monitoring, and other tasks requiring remote control over long distances.
Repeater Advantages
- Support for ELRS and TBS Crossfire modules — flexibility in choosing a control system.
- Wide control range of 433–2800 MHz for reliable communication.
- Video signal reception at 1.08–1.36 GHz and transmission to operator at 5800 MHz.
- Portable power from a 2S 21700 battery with up to 2 hours of autonomy.
- Easy integration with DJI aircraft via standard brackets and mounting kit (4 screws).
Technical Specifications
| Parameter | Description |
|---|---|
| Compatibility | DJI Matrice 30, DJI Matrice 300 (specify when ordering) |
| Operating Time | Up to 2 hours on a single charge |
| TX Module Support | ELRS, TBS Crossfire |
| Control Range | 433-2800 MHz |
| Control Antenna | Selectable in the 433 MHz - 2.8 GHz range (SMA connector) |
| Video Receive Antennas | SI 1.3GHz 10.3dBi Patch Antenna |
| Video Signal Range (Reception) | 1.08 - 1.36 GHz |
| Video Signal Transmission Frequency to Operator | 5800 MHz |
| Power Source | 2S 21700 Battery (1 pc.) |
| Mounting | 4 screws (included) |
| Package Contents | Repeater with all necessary modules and antennas, battery - 1 pc, mounting adapter - 1 pc. |
The SkyReach repeater is a well-designed combination of hardware compatibility, high reception sensitivity, and reliable 5.8 GHz video transmission. Mounting on standard DJI brackets simplifies integration, and the package includes everything needed for quick installation and startup. Before ordering, we recommend clarifying compatibility with the specific configuration of your DJI Matrice 300 or Matrice 30 drone.
