Experience a new level of stability and control in your wireless network with the HORN WiMAX antenna from TM «ROKS». This professional horn solution, specifically designed for operation in the wide 5050-6000 MHz range, provides powerful 20 dB gain and flawless signal directionality. Thanks to its basic configuration without unnecessary accessories, this antenna is an ideal choice for system integrators who value mounting flexibility and the ability to adapt equipment to the specific standards of a particular site.
Purpose
-
WiMAX integration projects in the 5050-6000 MHz range.
-
Creation of directional links between network nodes to minimize interference.
-
WiMAX signal relay in industrial and corporate communication systems.
-
Use in networks with saturated airwaves where precise coverage area control is required.
-
Building long-distance data transmission backbone segments.
Technical Specifications
| Characteristic | Value |
| Frequency Range | 5050-6000 MHz |
| Gain | 20 dB |
| Wave Impedance | 50 Ohm |
| Connector Type | SMA-female (2 pcs) |
| Polarization | Linear (vertical + horizontal simultaneously) |
| Weight | 1.2 kg |
| Dimensions | 224x224x405 mm |
| Finish | Unpainted, without cover |
Materials and Construction
-
Durable metal horn-type casing for maximum resilience.
-
Absence of external paint coating (basic version for individual needs).
-
Compact dimensions with high radio engineering performance.
-
Precision assembly from Ukrainian manufacturer TM «ROKS».
-
Design without fixed mounting for free integration into casing systems.
Functions and Capabilities
The horn shape of the antenna provides a narrow beamwidth, allowing for effective rejection of extraneous noise and concentration of energy in the desired direction. The presence of two SMA-female connectors and support for simultaneous linear polarization (V+H) opens up possibilities for working with modern data transmission protocols. The high gain of 20 dB compensates for losses in cable runs and guarantees a stable link even in adverse weather conditions.
Compatibility
-
Compatible with any WiMAX equipment operating within 5-6 GHz.
-
Connects to radio modules via standard coaxial cables with SMA connectors.
-
Can be installed in custom protective enclosures or on specialized brackets.
-
Full compatibility with repeaters and access points with 50 Ohm impedance.
Advantages
-
High 20 dB gain for stable communication over significant distances.
-
Wide operating frequency spectrum (5050-6000 MHz) for flexible frequency planning.
-
Ukrainian production with a full quality control cycle.
-
Minimalistic configuration, reducing costs for bulk purchases.
-
High interference immunity due to horn design.
Package Contents
-
HORN WiMAX horn antenna (1 pc)
-
Product passport (1 pc)
Packaging
-
Reliable packaging for safe transportation.
-
Absence of additional mounting elements and covers in the standard kit.
-
Option for bulk packaging for wholesale orders.
Warranty and Service
TM «ROKS» provides an official warranty for the HORN WiMAX antenna, confirming its reliability and compliance with stated parameters. Users have access to qualified technical support from the manufacturer and service in Ukraine.
Order the HORN WiMAX antenna today to provide your network with professional communication quality and time-tested stability.
