5.8/1.2GHz Dual-Frequency ELRS/TBS Repeater
Brand: SkyReach. This is a high-tech ground relay station from the Ground Relay Stations category, designed to significantly improve FPV communication quality and range for both professional and amateur flights.
The repeater supports two popular control systems — ELRS (ExpressLRS) and TBS Crossfire, with two TX modules operating in parallel for enhanced communication reliability. The device ensures simultaneous transmission of video signals and control commands, minimizing the risk of losing connection during long-range flights and complex shooting tasks.
Description and Purpose
This repeater is designed for integration into existing FPV systems and allows customization to individual operator needs. With support for two control frequencies and antenna selection, you gain flexibility in settings for specific tasks — real-time aerial monitoring, FPV racing, long-distance flights, or professional video shooting.
Key Advantages:
- Stable and reliable long-range communication thanks to parallel operation of ELRS and TBS modules.
- Simultaneous video and control command transmission — safe and controlled flights.
- Easy integration with existing FPV kits and customization for customer tasks.
- Suitable for professional FPV pilots and amateurs looking to expand flight boundaries.
Specifications:
Specifications| Compatibility | DJI Matrice 30, DJI Matrice 300 (specify when ordering) |
| Operating time | up to 2 hours on a single charge |
| TX module support | ELRS / TBS (2 modules operate in parallel in this repeater) |
| Control range | 2 frequencies for customer selection |
| Control antenna | 2 antennas for customer selection |
| Video reception antennas | SI 5.8GHz 19.5 dBi Patch antenna and Helix (27 turns) 18 dBi |
| Video signal range (reception) | 4.9 - 5.9 GHz |
| Video signal transmission frequency to operator | 1.2 GHz |
| Power elements | 2S 21700 battery (1 pc.), connector - XT30 |
| Mounting | 4 screws (included) |
| Package contents | Repeater with all necessary modules and antennas, battery - 1 pc., mounting adapter - 1 pc. |
The repeater allows the customer to choose optimal control antennas and control frequency settings, making it a universal solution for various application scenarios. The package includes all necessary components for quick installation and setup: control modules, video reception antennas, one 2S 21700 battery with XT30 connector, and a mounting adapter. The autonomous operating time of up to 2 hours allows for long observations and shooting without frequent battery changes.
This ground station is an ideal choice for those who need a combination of powerful video reception (4.9–5.9 GHz) and reliable control transmission at 1.2 GHz with the ability to use both ELRS and TBS Crossfire.
