Aeronetix FPV Video Channel Receiver Antenna 4.8 - 5.7 GHz

Name: FPV Video Channel Receiver Antenna 4.8 - 5.7 GHz
Manufacturer: Aeronetix
Category: Antennas > Log-Periodic Antenna

Brief Overview

The compact Aeronetix log-periodic antenna is designed for efficient FPV video signal reception in the high-frequency range. The original product name specifies a range of 4.8-5.7 GHz, making the antenna suitable for a wide array of FPV applications. Its design strikes a balanced compromise between wide bandwidth and signal directivity: high gain improves reception range, while a narrow beamwidth allows for more precise antenna focusing on the transmitter. This is a practical solution for drones, ground receivers, mobile FPV systems, and amateur networks where stability and video stream quality are crucial.

Technical Specifications

Key Parameters:

• Frequency Range: 4.8-5.7 GHz (stated in title and overview) and 4800-5500 MHz (4.8-5.5 GHz) — listed in the primary technical specification.
• Gain: 13 dBi.
• Beamwidth: 50/25 degrees.
• Dimensions (per primary description): 120×60×50 mm.
• Weight (per primary description): 55 g.

Note: The extended product attributes provide different values for dimensions and weight — this data is also provided below for a complete understanding of the product and selection of the optimal configuration.

Additional Product Parameters

Thus, you have a complete picture: the original description states dimensions of 120×60×50 mm and a weight of 55 g, while the attributes list length 6.0, width 12.0, height 5.0, and weight 0.100 kg (100 g). The difference in values may be due to different measurement methods, packaging, or antenna modifications. We recommend clarifying the final dimensions and weight before installation, especially if size or weight limitations are critical for your system.

Advantages of Use

• High gain of 13 dBi ensures improved signal reception at medium and long distances.
• The log-periodic design combines a wide operating range and directivity, which is important for stable FPV signal reception within the specified frequencies.
• Compact size and low weight (depending on data source: 55 g or 100 g) allow for integration into various platforms without significantly increasing the load.
• Versatile application: suitable for drones, ground receivers, mobile systems, and experimental solutions.

The Aeronetix antenna is a practical and reliable solution for users who need stable FPV video signal reception with high sensitivity and moderate directivity. Before installation, be sure to check the compatibility of connectors, mounts, and weight/dimension requirements for your equipment. If precise weight or dimensions are critical, clarify the information with a manager or in the supplier's technical documentation.
