Kulbaba TX 840-1010 MHz EW System «Kulbaba» — AWEDYNE

The Kulbaba TX 840-1010 MHz electronic warfare (EW) system is designed for effective suppression of FPV drone control channels and to enhance the safety of vehicle convoys, trenches, and stationary objects. This model is developed by AWEDYNE and belongs to the EW jammers product category, subcategory — Vehicle EW Jammers. The device is implemented as a mobile portable system, allowing for quick deployment on a vehicle and operation in field conditions.

The Kulbaba TX operates in the 840–1010 MHz range and specializes in FPV control suppression. Structurally, the system consists of independent blocks: each block has its own casing, a fixed antenna, and a separate connector for power supply from a portable battery. Power is supplied exclusively by the included LiFePo4 24 V, 12 Ah battery; connection to a vehicle's onboard power system or other power sources is not provided. The operating time of one battery set when operating two blocks is approximately 2.5 hours.

The antennas in each block are non-detachable and designed for a specific operating frequency; their fixed nature prevents the block from operating without an antenna, which protects the amplification elements from burnout. The antenna design is reinforced for increased mechanical resistance to vehicle vibrations and adverse weather conditions. Each block is equipped with neodymium magnets impregnated with a rubber layer, ensuring quick and reliable mounting on metal surfaces of transport.

Key Features

• Name: Kulbaba TX 840-1010 MHz EW System «Kulbaba»
• Manufacturer: AWEDYNE
• Category: EW Jammers; Subcategory: Vehicle EW Jammers (EW Jammers > Vehicle EW Jammers)
• Operating Range: 840–1010 MHz (FPV control suppression)
• Power Supply: LiFePo4 24 V, 12 Ah battery (included battery)
• Operating Time: Approximately 2.5 hours from one battery when two blocks are operating
• Design: Independent blocks with separate casings and antennas
• Antennas: Non-detachable, reinforced design for stability
• Mounting: Neodymium magnets with rubber impregnation for secure fixation

IMPORTANT!

• 1. Many devices resembling "Kulbaba" have appeared on the market, but the original system is produced only by AWEDYNE. Be careful when choosing — other products are not original.
• 2. Devices combining several ranges or multiple antennas in one casing may not operate correctly; for proper operation, antennas must be spaced apart from each other.
• 3. Collinear dipole whip antennas form a "doughnut-shaped" field with a vulnerable zone above the surface; for reliable protection, choose antennas that provide a dome-shaped coverage field.
• 4. Power only from the included battery; do not modify the device for vehicle power. If operating time is insufficient, purchase an additional battery set.
• 5. When choosing solutions with active cooling, consider the risks: active cooling can fail due to rain, snow, or contamination. It is recommended to choose solutions with passive cooling for increased reliability.

The Kulbaba TX 840-1010 MHz system from AWEDYNE is a portable, specialized solution for enhancing the protection of equipment and objects from remote-controlled FPV drones. Thanks to its modular design with independent blocks, non-detachable antennas, and magnetic mounting, installation and operation are maximally simple and reliable, and its technical specifications meet the requirements of field application conditions.
