Mini Tractor Foton-Lovol TE-244 REVERSE — Reliable Universal Wheel Mini Tractor
Model: Mini Tractor Foton-Lovol TE-244 REVERSE from manufacturer Foton (category: Tractors > Mini Tractors) is designed for a wide range of agricultural tasks, loading and unloading operations, transport, and municipal services. It is a compact and durable wheel mini tractor that combines functionality and ease of use on plots of various sizes.
Key Features and Purpose
The tractor is equipped with 4x4 all-wheel drive, with the front axle engaging only when necessary — this helps save fuel and reduce component wear. The engine is a three-cylinder diesel with water cooling. The power is stated as both 25 kW and 24 hp (17.6 kW) in different parts of the description, so when choosing a modification, pay attention to both values — they reflect different measurement methods and information from the technical passport. Based on its operating parameters, this mini tractor is suitable for cultivating land plots over 40,000 m².
Configuration and Options
The basic configuration allows for the installation of power steering, a cabin heater, an electric flare system for engine preheating, a reversible transmission, and a two-speed reverse. The tractor is also equipped with an electric starter with safe start, a dry twin-disc clutch, rear differential lock, reverse, and a dry-type braking mechanism (shoe brake). PTO speeds are 540/1000 rpm. If desired, the buyer can additionally purchase mounted or trailed equipment — the final price will vary depending on the set of attachments and options.
Recommended alternative models for comparison: Jinma 404, Shifeng 354, Dongfeng, Xingtai, Foton, Zoomlion, DTZ 5244, Bulat 454, Bulat 250, Bulat 254, Belarus 320.4, Shifeng 350 L, DW 244, DTZ 5404K, Tractor Solis 26, Solis 50, Shifeng SF-244.
Our company offers various options for high-quality mini tractors — it's easy to choose a model by operating parameters and cost; contact our managers for consultation and selection of attachments for specific tasks.
Technical Specifications
| Engine Power (kW) | 24 hp (17.6) |
| Wheel Formula | 4x4 |
| Engine Type | 4-stroke water-cooled diesel engine |
| Engine Start | electric starter with safe start |
| Engine Displacement, cm3 | 1 532 |
| Rated Fuel Consumption g / kWh | ≤278 |
| Rated Engine Crankshaft Speed rpm | 2 350 |
| Rated Traction Force, kN | 6.5 |
| Transmission (Gearbox) | non-synchronized mechanical with reverse (4 forward + 4 reverse) * 2 |
| Rear Differential Lock | Yes |
| Clutch | Dry, twin-disc |
| Power Steering | Yes |
| Reverse | Yes |
| Braking Mechanism | dry type, shoe brake |
| Power Take-Off (PTO) Speed rpm | 540/1000 |
| Wheelbase, mm | 1 660 |
| Front Wheel Track, mm | 1 265 |
| Rear Wheel Track, mm | 960~1 460 |
| Front Tire Size | 6.5 - 16 |
| Rear Tire Size | 11.2- 24 |
| Theoretical Forward Speed, km / h | 26.02 |
| Theoretical Reverse Speed km / h | 24.24 |
| Fuel Tank Capacity, L | 32 |
| Engine Crankcase Volume, L | 5.0 |
| Gearbox and Rear Axle Crankcase Volume, L | 20.0 |
| Lift Housing Volume, L | 9.0 |
| Front Axle Crankcase Volume, L | 6.0 |
| Engine Cooling System Volume, L | 10 |
| Overall Dimensions (LxWxH), mm | 3453/ 1440/ 2495 |
| Structural Weight, kg | 1340 |
This information includes all parameters and descriptions specified in the original product description: engine, transmission, hydraulics, and dimensions. If you need help choosing attachments or selecting a tractor for specific tasks, please contact our managers.
