Mini Tractor Bulat 254 TF LUX — Updated Luxury Model 2020
The Bulat 254 TF LUX mini tractor is a full-wheel drive (4x4) compact and versatile machine from the Bulat brand, designed for private farms, small businesses, and utility work. The model combines robust construction, enhanced off-road capability, operator comfort, and a favorable price for customers in Ukraine. The tractor is suitable for seasonal field work, soil cultivation, transport with a trailer, and operation with mounted equipment.
Engine and Fuel System
The installed four-stroke diesel engine KM385 with direct injection delivers 24 hp (17.65 kW). The engine has 3 vertically arranged cylinders and a displacement of 1532 cm3. For ease of operation, an electric starter is provided, and the nominal crankshaft speed is 2350 rpm.
Cooling, Transmission, and PTO
The cooling system is a closed liquid type with forced circulation, ensuring stable engine operation under prolonged loads and high temperatures. The gearbox has a (4+1)x2 scheme, and the main drive is direct. There is a rear differential lock for better off-road capability. The clutch is a dry, single-disc, constantly closed type. The power take-off (PTO) shaft is rear, splined with modes of 540 / 1000 rpm.
Chassis, Tires, and Off-Road Capability
The mini tractor is equipped with front tires sized 6.50-16 and rear tires sized 11.20-24 with a chevron ("herringbone") tread, ensuring reliable grip on various types of soil, including wet surfaces. The minimum ground clearance is 340 mm, the wheelbase is 1639 mm, and the nominal traction force is 6.1 kN.
Hydraulics, Steering, and Comfort
The hydraulic system operates based on a gear pump (NSH) for powering the hitch and an NSH for power steering operation. 2 hydraulic outlets are provided. The tractor is equipped with power steering (GUR) for easier control and reduced effort during maneuvering. Operator comfort is enhanced by a spring-loaded seat, an hour meter, and the side location of the gear lever. Rear weights are provided for working with mounted equipment.
Capacities, Volumes, and Weight
The fuel tank capacity is 24 L. The engine crankcase volume is 5 L, the gearbox and rear axle crankcase volume is 26 L, and the front axle crankcase volume is 6 L. The tractor's curb weight is 1320 kg. There is a trailer connector (socket) for convenient connection of trailers and mounted equipment.
Model advantages: 4x4 full-wheel drive, reliable KM385 diesel engine with electric starter, efficient liquid cooling system, rear differential lock, versatile transmission, wide tires with chevron tread, power steering, ergonomic seat, and a set of options for working with various mounted equipment. This makes the Bulat 254 TF LUX an optimal choice for household, agricultural, and utility work.
How to place an order: add the tractor to your cart on the product page and leave your contact details — our managers will contact you to clarify delivery and provide consultation. The Bulat 254 TF LUX mini tractor is a quickly repaying investment thanks to its versatility and reliability.
Technical specifications:
| Engine power, hp (kW) | 24 (17.65) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, with direct injection, KM385 |
| Number and arrangement of cylinders | 3, vertical |
| Engine start system | electric starter |
| Cooling system | liquid, closed, with forced circulation of coolant |
| Engine displacement, cm3 | 1532 |
| Nominal engine crankshaft speed, rpm | 2350 |
| Nominal traction force, kN | 6.1 |
| Gearbox (КП) | (4+1)x2 |
| Rear differential lock | Yes |
| Clutch | dry, single-disc, constantly closed type |
| Main drive | direct |
| Power take-off (PTO) shaft | rear, splined |
| Hydraulic system pump type | gear pump (NSH) for hitch drive / NSH for power steering operation |
| PTO shaft speed, rpm | 540 / 1000 |
| Minimum ground clearance, mm | 340 |
| Wheelbase, mm | 1639 |
| Tire size | front 6.50-16, rear 11.20-24 |
| Fuel tank volume, L | 24 |
| Engine crankcase volume, L | 5 |
| Gearbox and rear axle crankcase volume, L | 26 |
| Front axle crankcase volume, L | 6 |
| Number of hydraulic outlets | 2 |
| Trailer connector (socket) | + |
| Power steering | + |
| Hour meter | + |
| Spring-loaded seat | + |
| Side location of gear lever | + |
| Rear weights | + |
| Curb weight, kg | 1320 |
