Mini Tractor KATA KE 604D
Brand: KATA. The KATA KE 604D mini tractor is a powerful and reliable 4x4 unit designed for a wide range of agricultural, municipal, and transport tasks. The model combines efficiency, high productivity, and versatility for use with various attachments.
Key Features at a Glance:
- Engine Power: 60 hp (44.1 kW).
- Engine Type: Diesel, 4-stroke SD490ZT2, 4 cylinders, vertical arrangement, 2770 cm3 displacement.
- Starting System: Electric starter for quick and reliable ignition.
- Cooling: Liquid-cooled closed system with forced circulation, fan driven by V-belt.
- Transmission: (4+1)x2 (transport and work modes) with rear differential lock for improved off-road capability.
- Power Take-Off (PTO): Rear, splined, 540/720 rpm modes.
The mini tractor is equipped with a dry single-disc clutch of permanently closed type, direct main drive, and hydraulic power steering for comfortable operation. The braking system is implemented on the secondary shaft of the gearbox with brake drums, ensuring reliable braking in various conditions.
Its economic performance and traction make the KATA KE 604D efficient for heavy-duty tasks: nominal fuel consumption ≤235 g/kWh, nominal traction force 13.31 kN. The lifting capacity for attachments is 850 kg, allowing for the use of a wide range of implements and units, while the presence of two hydraulic outlets and a gear pump (HP) for attachment drive and power steering operation enhances the machine's versatility.
The model's dimensions and chassis are designed for field and municipal conditions: front tire size 7.0-12, rear 14.0-16; front wheel track 1050 mm, rear 1100–1350 mm; ground clearance 265 mm. The tractor's curb weight is 1720 kg, dimensions LхWхH: 3400х1430х2265 mm.
Detailed technical specifications for the KATA KE 604D model are provided below:
| Engine power, hp (kW) | 60 (44.1) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, SD490ZT2 |
| Number and arrangement of cylinders | 4, vertical |
| Engine starting system | electric starter |
| Cooling system | liquid, closed, with forced circulation of coolant |
| Cooling system fan drive | V-belt drive |
| Engine displacement, cm3 | 2770 |
| Nominal engine fuel consumption, g/kWh | ≤235 |
| Nominal traction force, kN | 13.31 |
| Transmission (КП) | (4+1)x2 |
| Rear differential lock | + |
| Clutch | dry 1-disc permanently closed type |
| Main drive | direct |
| Steering | hydraulic |
| Brakes | on secondary gearbox shaft, brake drums |
| Power Take-Off (PTO) | rear, splined |
| Hydraulic system pump type | gear pump (HP) for attachment drive / HP for power steering operation |
| Attachment lifting capacity | 850 kg |
| Power Take-Off (PTO) speed, rpm | 540/720 |
| Tire size | front 7.0-12, rear 14.0-16 |
| Wheel track | front 1050, rear 1100-1350 |
| Ground clearance, mm | 265 |
| Number of hydraulic outlets | 2 |
| Dimensions LхWхH mm | 3400х1430х2265 |
| Curb weight, kg | 1720 |
The KATA KE 604D is suitable for farms, private sectors, and municipal enterprises that require a robust and durable unit with good features. A reliable transmission, powerful and economical diesel engine, rear splined PTO with 540/720 rpm modes, as well as an 850 kg lifting capacity and two hydraulic outlets make this mini tractor a versatile solution for plowing, soil cultivation, work with attachments, and cargo transportation.
