John Deere 3045B Mini Tractor — A Powerful and Reliable Assistant for Your Farm
The John Deere 3045B model from the renowned manufacturer John Deere is a versatile mini tractor from the Tractors > Mini Tractors category, designed for a wide range of agricultural, utility, and municipal tasks. The combination of a reliable XinChai diesel engine, high cross-country capability, and well-engineered mechanics makes this tractor an optimal choice for farms, private plots, and municipal services.
Key Advantages and Purpose
45 hp (33.1 kW) power ensures confident operation with mounted and trailed equipment. 4x4 drive and rear differential lock enhance cross-country capability on difficult terrain. The (4+4)x3 gearbox provides a wide range of gears for various operations. For comfortable control, power steering with a separate pump and oil reservoir is provided.
The John Deere 3045B is equipped with a power take-off (PTO) shaft with 540/720 rpm modes, allowing connection of mowers, cultivators, trailed seeders, and other equipment. A reliable hydraulic system with a gear pump and a maximum mounted mechanism lifting capacity of 930 kg guarantees efficient operation with various implements. Ease of maintenance and availability of spare parts make operation convenient and economical.
Below are the full technical specifications for the John Deere 3045B model:
| Tractor power, hp (kW) | 45 (33.1) |
| Wheel formula | 4x4 |
| Engine type | vertical, 4-cylinder, 4-stroke XinChai diesel |
| Engine displacement, cm3 | 2977 |
| Cylinder bore / piston stroke | 95x105 |
| Nominal engine fuel consumption, g/kW*h | ≤238 |
| Fuel pump type | plunger, in-line |
| Nominal engine crankshaft speed, rpm | 2350 |
| Engine oil type | mineral or semi-synthetic for diesel engines |
| Gearbox (transmission) | (4+4)x3 |
| Transmission oil type, rear axle | transmission fluid |
| Front axle oil type | transmission fluid |
| Rear differential lock | + |
| Clutch | dry, single-disc |
| Power steering | with separate pump and oil reservoir |
| Cooling system fan drive | V-belt drive |
| Braking mechanism | drum type |
| Power take-off (PTO) shaft speed, rpm | 540/720 |
| Hydraulic system pump type | gear pump |
| Maximum lifting capacity of mounted mechanism, kg | 930 |
| Minimum ground clearance, mm | 305 |
| Wheelbase, mm | 1960 |
| Tire size | rear 11.20-28.00, front 7.50-16.00 |
| Minimum turning radius, m | with one-sided brake 3.8, without brake 4.4 |
| Fuel tank capacity, L | 65 |
| Overall dimensions (LxWxH), mm | 3570x1770x2100 |
| Curb weight, kg | 2000 |
The model is distinguished by its fuel efficiency — nominal fuel consumption is ≤238 g/kW*h, which, combined with an efficient transmission, reduces operating costs. A 65-liter fuel tank ensures long operation without frequent refueling. A ground clearance of 305 mm and dimensions of 3570x1770x2100 mm make the tractor maneuverable and stable in challenging conditions.
The John Deere 3045B offers ease of maintenance (dry single-disc clutch, drum brakes, V-belt fan drive), a reliable design, and availability of spare parts. If you need a robust, multifunctional, and economical mini tractor for agricultural, utility, or municipal tasks, the John Deere 3045B will be an excellent solution.
