Foton-Lovol FT454 SC Mini Tractor — Compact Power and Versatility
The Foton-Lovol FT454 SC mini tractor from the Foton brand is a reliable 45 hp (33.1 kW) diesel mini tractor designed for a wide range of tasks: plowing, soil cultivation, cleaning, transportation, and working with mounted and trailed equipment on a farm or in a municipal economy. The machine's design combines 4x4 all-wheel drive, a well-engineered transmission, and efficient hydraulics, allowing the FT454 SC to be used with various mounted implements and ensuring stable operation in challenging conditions.
Technical Specifications:
| Engine power, hp (kW) | 45 (33.1) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, A495BT |
| Number and arrangement of cylinders | 4, vertical |
| Engine start system | electric starter |
| Cooling system | liquid, closed, with forced circulation of cooling fluid |
| Cooling fan drive | V-belt drive |
| Engine displacement, cm3 | 2980 |
| Nominal engine fuel consumption, g/kWh | ≤238 |
| Nominal traction force, kN | 12.0 |
| Gearbox (transmission) | (4x3)+(4x3) |
| Rear differential lock | + |
| Clutch | dry 2-disc, constantly closed type |
| Main drive | direct |
| Steering control | hydraulic |
| Brakes | on rear wheels, disc, with mechanical drive, dual pedals |
| Power take-off (PTO) shaft | rear, splined |
| Hydraulic system pump type | gear pump (NSH) for implement drive / NSH for power steering operation |
| Mounted implement lifting capacity | 670 kg |
| Power take-off (PTO) shaft speed, rpm | 540/1000 |
| Tire size | front 8.30-20, rear 12.4-28 |
| Wheel track | front 1300, 1500, rear 1220, 1300, 1500, 1620 |
| Ground clearance, mm | 350 |
| Number of hydraulic outlets | 2 |
| Trailer connector (socket) | + |
| Compressor | + |
| Dimensions LxWxH mm | 4150x1610x2550 |
| Curb weight, kg | 2726 |
The A495BT engine with a displacement of 2980 cm3 and a power of 45 hp provides a confident traction reserve for working with plows, seeders, mowers, and other mounted equipment. The electric starter simplifies starting in all weather conditions, while the liquid closed cooling system with forced circulation and V-belt fan drive ensure stable temperature during prolonged loads. A nominal fuel consumption of up to ≤238 g/kWh contributes to economical operation.
The (4x3)+(4x3) transmission provides a wide range of speeds for field work and transportation. The rear differential lock, along with a reliable dry 2-disc clutch, enhances off-road capability and control on difficult terrain. Hydraulic steering and a gear pump for the hitch, plus a pump for power steering, allow for precise and effortless operation with mounted equipment.
The rear splined power take-off shaft with 540/1000 rpm modes is compatible with most trailed and mounted implements. The mounted implement lifting capacity of 670 kg allows for efficient use of medium and small attachments. Disc brakes on the rear wheels with mechanical drive and dual pedals enhance safety when working on slopes and during transportation.
The 4x4 wheel formula, front tire sizes 8.30-20 and rear 12.4-28, along with a ground clearance of 350 mm, guarantee good passability over various types of soil. The ability to adjust the track width (front 1300/1500 mm; rear 1220/1300/1500/1620 mm) allows the tractor to be adapted to row spacing and crop specifics. Compact dimensions of 4150x1610x2550 mm and a curb weight of 2726 kg ensure stability when working with heavy mounted mechanisms.
The Foton-Lovol FT454 SC comes equipped with a trailer socket, compressor, and two hydraulic outlets, making it a versatile solution for farmers, municipal enterprises, and private households that require a reliable and functional mini tractor.
Brand: Foton. Product category: Tractors > Mini Tractors.
