Mini Tractor DW 244A — Description and Advantages
The DW 244A mini tractor from manufacturer DW is a versatile and reliable unit for household and farm work. This model combines compactness, sufficient power, and all-wheel drive, making it suitable for plowing, tilling, sowing, fertilizing, clearing grass and hay, snow removal in winter, and transporting goods with a hitch. Category: Tractors > Mini Tractors.
Key Features
- 24 hp engine, allowing for a wide range of agricultural tasks.
- 4x4 all-wheel drive for better проходимость in difficult conditions.
- Electric starter for convenient engine ignition.
- High ground clearance (maximum clearance 330 mm) and large wheels for maneuvering on challenging terrains.
- Rear drum brakes for reliable braking; mechanical steering.
- Driver's seat with shock absorber and adjustment for operator height and weight for comfortable operation.
- Powerful hitch and towing device, hitch mechanism lifting capacity up to 350 kg.
- Large rearview mirrors for working in the dark.
- Recommended oil types: mineral or semi-synthetic for diesel engines.
The original description text retains an important detail: the engine is mentioned as two-cylinder in the general description, while the technical specifications list a three-cylinder option. This information is also left for transparency and clarification when choosing or contacting the seller.
Recommended alternatives: Jinma 404, Shifeng 354, Dongfeng, Xingtai, Foton, Zoomlion, DTZ 5244, Bulat 454, Bulat 250, Bulat 254, Belarus 320.4, Shifeng 350 L, DW 244, DTZ 5404K, Tractor Solis 26, Solis 50, Shifeng SF-244.
Technical Specifications:
| Power: | 24 hp |
| Wheel formula: | 4x4 |
| Engine type: | vertical, 3-cylinder 4-stroke diesel with forced water cooling and direct injection |
| Start: | electric starter |
| Cylinder volume (displacement): | 1417 cm3 |
| Cylinder bore/piston stroke: | 95x100 mm |
| Nominal engine fuel consumption: | 272 g/kWh |
| Pump type (fuel): | plunger |
| Nominal RPM: | 2200 rpm |
| Nominal traction force: | 5.5 kN |
| Engine oil type: | mineral or semi-synthetic for diesel engines |
| Engine oil consumption: | 2.31 g/kWh |
| Transmission: | (4+1)x2 |
| Transmission and rear axle oil type: | transmission oil |
| Clutch: | dry, single-disc |
| Braking mechanism: | drum type |
| PTO RPM: | 540, rear |
| Hydraulic system pump type: | gear pump |
| Maximum hitch mechanism lifting capacity: | 350 kg |
| Maximum clearance: | 330 mm |
| Wheelbase: | 1440 mm |
| Rear wheel track: | 900-1020 mm |
| Front wheel track: | 950 mm |
| Rear tire size: | 8.30x24 |
| Front tire size: | 4.00x16 |
| Minimum turning radius without brakes: | 2.8±0.2 m |
| Minimum turning radius with one-sided brake: | 2.4±0.2 m |
| Theoretical forward speed: | 2.11-32.19 km/h |
| Theoretical reverse speed: | 1.68-7.75 km/h |
| Fuel tank capacity: | 17 L |
| Engine crankcase capacity: | 3 L |
| Engine cooling system capacity: | 6 L |
| Lift housing capacity: | 5 L |
| Dimensions, LxWxH (in technical table): | 2654 x 1296 x 1365 mm |
| Dimensions (mentioned in text): | 3350 x 1500 x 1860 mm |
| Weight: | 1130 kg |
The DW 244A mini tractor combines reliability and versatility: nominal traction force of 5.5 kN, rear PTO 540 rpm, (4+1)x2 transmission, dry single-disc clutch, and transmission oil for the gearbox and axles. The hitch mechanisms and the possibility of using various attachments make the DW 244A a practical solution for small and medium-sized farms. Pay attention to the oil selection recommendations (mineral or semi-synthetic for diesel engines) and the presence of an electric starter for easier engine ignition. Brand: DW.
