The Promin Repeater by BlueBird is an integrated solution in the form of a high-performance FPV drone, specifically designed to significantly increase the range and stability of video and telemetry communication. The model combines a powerful hardware platform and a built-in repeater module, making it convenient for professional flights, monitoring, observation, rescue operations, and other critically important tasks.
Key Features and Benefits
-
Optical Stabilization: The drone maintains altitude, heading, and position without using GPS/GNSS, ensuring stable operation at altitudes from 50 to 1000 meters.
-
Rotary Antennas: Mechanisms for rotating antennas guarantee optimal positioning of communication modules and improve the quality of signal reception and transmission.
-
Autonomy: A high-performance battery provides up to 30 minutes of flight time, allowing for long missions without frequent landings.
-
Integrated Repeater: The repeater module is built directly into the drone's body, simplifying operation, maintenance, and increasing system reliability during flights in challenging conditions.
The Promin Repeater by BlueBird is ideal for situations requiring high-quality and reliable communication over significant distances: high-speed FPV competitions, professional aerial photography, territory control, search and rescue operations, and other tasks where reaction time and transmission stability are critical.
Technical Specifications
Drone Specifications
| Parameter | Value |
|---|---|
| Motors | 3115 900KV |
| Flight Controller | Speedy Bee F405 V3 |
| ESC | Foxeer 65A |
| Video Transmitter (VTX) | Rush Max Solo (2.5 W) |
| Telemetry | ELRS HappyModels 915 MHz |
| Battery | 6S3P, 15000 mAh |
Repeater Specifications
| Parameter | Value |
|---|---|
| Receiver (VRX) | Skyzone SteadyView X 5.8G |
| Video Transmitter (VTX) | Readytosky 1.2G 1000 mW |
| Telemetry | TBS 915 MHz |
| Antennas | - Helix 5.8 GHz, 17 dBi (21 turns) - Helix 5.8 GHz, 14 dBi (16 turns) - Mini Yagi 915 MHz, 9 dBi (or alternative frequency by choice) |
Package Contents
- 1. Promin Repeater by BlueBird.
Manufacturer: BlueBird.
Product Type: Ground Repeater Stations.
This model combines proven hardware platform components (3115 900KV motors, Speedy Bee F405 V3 controller, Foxeer 65A ESCs) and professional communication modules (VTX Readytosky 1.2G 1000 mW, VRX Skyzone SteadyView X 5.8G, TBS 915 MHz / ELRS HappyModels 915 MHz telemetry). A high-capacity 6S3P 15000 mAh battery provides up to 30 minutes of autonomous operation, and various antennas (Helix 5.8 GHz 17 dBi and 14 dBi, Mini Yagi 915 MHz 9 dBi) allow for configuration selection based on task and frequency requirements.
The integration of the repeater into the drone's body allows for quick system deployment in field conditions, reduces setup time for external components, and increases the overall reliability of the complex. Thanks to rotary antennas and optical stabilization, the drone maintains a stable link even when performing agile tasks at altitudes from 50 to 1000 meters.
If you need a mobile, reliable, and easy-to-use repeater complex for tasks requiring stable communication over long distances, the Promin Repeater by BlueBird will be the optimal choice.
