TBS Mambo Radio — Professional FPV Radio Controller
TBS Mambo — is a professional remote control from the TBS brand, designed for enthusiast pilots and professionals who require minimal latency, stable long-range communication, and high ergonomics. The device features a built-in TBS Tracer module and is compatible with the TBS Crossfire module via the JR bay, ensuring reliable communication for long-range missions. The operating system is the open-source FreedomTX (an OpenTX fork), which provides extensive customization options and flexibility for experienced users.
Advantages and Key Features
The TBS Mambo stands out with its very low end-to-end latency of 1.6 ms and a high polling rate of 250 Hz, allowing for maximum control sensitivity during fast FPV flights. The remote provides high telemetry bandwidth, Mavlink support, integration with TBS Cloud, and convenient menu navigation using a keypad dial and three buttons.
| Advantage | Description |
|---|---|
| End-to-End Latency | 1.6 ms – one of the best in TBS Mambo |
| Refresh Rate | 250 Hz for maximum sensitivity of the TBS Mambo remote control |
| Operating Range | Capable of long-range operation |
| Telemetry | High telemetry bandwidth for Mavlink and long-range missions |
| Cloud Connectivity | TBS Cloud connection for TBS Mambo |
Functions and Hardware Features
The remote's body features an ergonomic design with grippy rubber edges, a perfectly balanced lanyard mount for comfortable carrying, and full-size Hall sensor gimbal bearings. The joysticks are equipped with adjustable resistance and tension, adjustable throttle and tilt angle (+/- 10°), and a spare set of springs for reduced tension. The remote has a built-in antenna and is designed to work with an additional external antenna for maximum range, supporting the CRSF V3 protocol for the lowest latency and a maximum range of up to 25 km (15 miles).
| Feature | Details |
|---|---|
| Built-in TBS Tracer | Unique integration into the TBS Mambo remote control |
| Data Transmission Protocol | CRSF V3 protocol support for lowest latency |
| Range | Up to 25 km / 15 miles on TBS Mambo |
| Antennas | Built-in antenna for maximum range and external auxiliary antenna |
| Gimbal Mechanism | Full-size Hall sensor gimbal bearing |
| Adjustments | Adjustable resistance and tension, adjustable throttle and joystick tilt angle (+/- 10°) |
| Included Accessories | Spare set of springs for lower tension |
| Ergonomics | Ergonomic body design with grippy rubber edges |
| Controls | 4 x 3-position switches, 2 x center-detent potentiometers, 1 x 2-position switch, 1 x momentary button, 4 digital trim buttons |
| Portability | Perfectly balanced lanyard mount |
| Channels | Up to 12 channels supported |
| Audio | Audio output with headphone jack and haptic vibration alert |
| Operating System | FreedomTX (OpenTX fork) |
| Menu Navigation | Keypad dial and 3-button menu for easy navigation |
| Display | High-resolution black and white LCD screen (128 x 64) |
| Model Memory | 100+ model memory, SD card included |
| Cloud Integration | TBS Cloud compatible |
Technical Specifications
| Parameter | Value |
|---|---|
| TBS Mambo Weight | 565 g |
| Battery | 2 x 18650 (not included) |
| Audio | 1W speaker and 3.5mm headphone jack |
| TBS Mambo Display | 3.5-inch LCD panel (128 x 64) |
| Antenna | Built-in antenna (internal) |
| Switches | 4 x 3pos | 1 x 2pos | 1 x Momentary |
| USB-C Port | Battery charging (5V, 1A), firmware updates, and simulator/HID mode |
Package Contents
| Component | Quantity, pcs. |
|---|---|
| TBS Mambo Remote Control | 1 |
| Spring Set (with lower tension) | 1 |
| Throttle Limit Screws (with hex key) | 2 |
Who is the TBS Mambo suitable for?
This remote is ideal for pilots performing long-range missions, aerial photography, video shooting, or participating in FPV competitions. If minimal latency of 1.6 ms, a high refresh rate of 250 Hz, Mavlink telemetry support, large model memory, and cloud services are important to you — the TBS Mambo will be a reliable tool for work and hobby. Brand: TBS. Category: Drones & Quadcopters > Remote Controls.
