Transmitter Module TX COALAS::17TX, 150-170, 10W
Brief Description
The COALAS::17TX transmitter module from Coalas systems is a professional solution for FPV operators and UAV system integrators who require reliable, secure, and high-power radio transmission. Designed for operation in challenging conditions and under active electronic warfare (EW) interference, the device offers flexible operating range configuration, rapid preset changes, and a high level of protection for control packets and telemetry.
Purpose and Compatibility
COALAS::17TX is suitable for long-range radio communication systems, professional FPV projects, and unmanned platforms where high configuration dynamics, interference immunity, and integration with modern control protocols are required. The module is compatible with common controllers and RX platforms, allowing for quick integration into existing solutions.
Technical Specifications
| Parameter | Value |
|---|---|
| Frequency Range | 150–170 MHz |
| Transmit Power | 50 mW – 10 W |
| Sensitivity | –134 dBm |
| Firmware | ImpactLRS / MILELRS |
| Protocol | CRSF (UART) |
| Antenna Connector | IPEX |
| Power Supply (TX) | JR: 8.4 – 12.6 V; XT30: 12.6 – 26 V (3S – 6S) |
| Consumption | up to 40 W |
| Receiver Dimensions | 23×20 mm |
Features and Functions
- A large number of frequency hopping spread spectrum (FHSS) presets accessible via the LUA menu for quick adaptation of the transmitter to local spectrum conditions and minimization of interference.
- The ability to create custom range and FHSS hop settings gives the operator full control over the frequency strategy and allows for optimized operation in specific conditions.
- TURBO mode — activation of maximum power via AUX channel to penetrate EW domes in critical situations.
- Synchronous TX and RX reconfiguration ("Backpack mode") simplifies link setup and ensures consistent transmitter and receiver parameters.
- Telemetry is disabled by default in "radio silence" mode, providing an additional option for covert operation.
- Web-flasher for firmware updates (available for verified users) facilitates maintaining up-to-date software.
- Fast encryption algorithms for control packets and telemetry with a 256-bit protection key guarantee a high level of security for control and data transmission.
Communication Range
- Operational: up to 80 km
- Maximum: up to 120 km
The COALAS::17TX module combines high power (from 50 mW to 10 W), sensitive reception (–134 dBm), and effective countermeasures against electronic interference, making it an optimal choice for tasks requiring efficient and secure radio communication. Support for ImpactLRS and MILELRS firmware, as well as the CRSF (UART) protocol, ensures compatibility with modern control and telemetry solutions.
Brand: Coalas systems. Product category: Drones & Quadcopters > Drone Components > Drone Parts > Transmitters.
If you need a powerful, secure, and flexibly configurable transmitter module with support for modern firmware and protocols, the COALAS::17TX will meet the requirements of professional operators and integrators.
