200 MHz Anti-FPV Module for EW «KUPOL-M»

The 200 MHz Anti-FPV Module for EW KUPOL-M from Sector-M is a specialized electronic warfare module designed for reliable suppression of FPV drones in critical situations. The device integrates into the «KUPOL-AUTO» system, which operates in the same frequency range and has a total power of 50 W, providing effective airspace protection against small unmanned aerial vehicles.

Key technical specifications and capabilities of this module include a frequency range of 200-300 MHz with a power of 50 W, allowing it to jam FPV drone signals at distances from approximately 70 meters to 200 meters depending on application conditions. The module's design features sectoral radiation: 360˚ horizontally and 180˚ vertically, without a "hole" at the top, enabling coverage of the space above the target without dead zones.

• Frequency range: 200-300 MHz, module power — 50 W.
• FPV drone jamming range: 70 m to 200 m, depending on conditions.
• Radiation sector: 360˚ horizontally and 180˚ vertically — no "hole" at the top.
• Antennas protected from external influences for reliable operation in field conditions.
• Magnetic mounting for quick installation and removal of modules.
• Power consumption: 100–120 W; power supply: 12–24 V with internal converters providing stable 28 V for the radio module.
• Battery life: up to 5 hours under optimal operating conditions.

The module was developed by Sector-M and belongs to the product category: EW Jammers > EW Components > Modules. It is designed for integration into electronic warfare systems and can be used in mobile and stationary configurations thanks to convenient magnetic mounting and protected antennas. Built-in power converters ensure stable operation of the radio module with variable input power of 12–24 V, making the device compatible with standard power sources and battery packs.

This module is effective where local suppression of FPV drone control channels is required, for example, to protect the perimeter of objects, temporary camps, or other critical zones. Given its design features and technical parameters, the module provides a balance between jamming power and energy consumption, allowing for up to 5 hours of autonomous battery operation.

Other important details: manufacturer — Sector-M; product identified in the system under number 26952; model optimized for operation as part of the «KUPOL-AUTO» system, which provides an effective level of protection against FPV drones in the 200–300 MHz frequency range.
