DW 244 ATM Mini Tractor — Power and Reliability from the DW Brand
The DW 244 ATM mini tractor is a versatile compact tractor, an improved modification of the classic A-model. It is equipped with an upgraded 3-cylinder diesel engine with 24 hp (17.65 kW), features 4x4 all-wheel drive, differential lock, and a good configuration for a wide range of agricultural, municipal, and general utility tasks. This model combines enhanced engine reliability, maneuverability, and fuel efficiency, making it an attractive choice for small farms and private users.
Key advantages of the DW 244 ATM:
- 24 hp (17.65 kW) 3-cylinder diesel engine with vertical cylinder arrangement — provides greater engine life and durability compared to previous 2-cylinder solutions.
- 4x4 all-wheel drive, rear differential lock, and robust tires sized 6.50-16 / 9.50-24 for high проходимость on any terrain.
- Convenient configuration: adjustable seat with suspension, dashboard with sensors, electric trailer socket, headlights, horn, mirrors, front and rear hitches, protective fenders, battery disconnect switch, and additional rear light.
- Economical operation: with proper maintenance and use, the DW 244 ATM quickly pays for itself thanks to an optimal combination of price, reliability, and wide range of attachments.
- Support from the official representative in Ukraine — the "MotoKosmos" online store, which provides consultations and delivers across the country.
Differences sometimes occur between the review text and the technical specifications: the review mentions a maximum lifting capacity of 500 kg and dimensions of 3350x1500x1860 mm with an unladen weight of 1265 kg, while the official technical parameters, provided in the table below, indicate a hitch lifting capacity of 450 kg, dimensions of 3300x1460x1880 mm, and a weight of 1298 kg. We recommend referring to the official technical specifications when making a purchase decision.
DW 244 ATM Technical Specifications
| Power: | 17.65 kW / 24 hp |
| Fuel: | Diesel |
| Number and arrangement of cylinders: | 3, vertical |
| Cooling system: | Water-cooled |
| Engine displacement: | 1531.33 cc |
| Cylinder diameter / piston stroke: | 85 / 90 mm |
| Engine type: | 4-stroke |
| Starting system: | Electric starter |
| Cooling fan drive: | V-belt drive |
| Fuel consumption: | ≤275 g/kWh |
| Engine oil consumption: | 2.31 g/kWh |
| Crankshaft speed: | 2300 rpm |
| Tractive effort: | 5.8 kN |
| Transmission: | (4 + 1)x 2 |
| Wheel formula: | 4x4 |
| Engine oil type: | Mineral or semi-synthetic for diesel engines |
| Transmission and rear/front axle oil type: | Silver SAE 85W-90; Gold SAE 80W-90; Platinum SAE 75W-90 (transmission oil) |
| Differential lock: | Yes |
| Steering: | Mechanical |
| Final drive: | Direct |
| Hydraulic system pump type: | Gear pump for hitch drive |
| Maximum hitch lifting capacity: | 450 kg |
| Power take-off (PTO): | Rear, splined |
| PTO speed: | 540/720 rpm |
| Fuel tank capacity: | 18.5 L |
| Engine crankcase capacity: | 6.6 L |
| Transmission and rear axle crankcase capacity: | 14 L |
| Front axle crankcase capacity: | 4 L |
| Engine cooling system capacity: | 6 L |
| Minimum ground clearance: | 300 mm |
| Wheelbase: | 1720 mm |
| Front / rear wheel track: | 1220/1440, 1120-1450 mm |
| Front / rear tire size: | 6.50-16 / 9.50-24 |
| Minimum turning radius with brakes: | 3.25 m |
| Minimum turning radius without brakes: | 4.5 m |
| Forward speed: | 2.11-32.19 km/h |
| Reverse speed: | 1.68-7.75 km/h |
| Overall dimensions: | 3300x1460x1880 mm |
| Weight: | 1298 kg |
The DW 244 ATM model is ideal for owners of small farms, municipal enterprises, and private users who need a reliable mini tractor with all-wheel drive and a wide range of attachments. Brand: DW. Product category: Mini Tractors.
For additional information, availability, and delivery terms, please contact the official representative — the "MotoKosmos" online store. Free consultation and shipping across Ukraine are available.
