Yanmar F-210 Mini Tractor — Overview and Specifications
Model: Yanmar F-210 Mini Tractor. Manufacturer: Yanmar. Product Type: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mini Tractors. The compact, reliable, and economical Yanmar F-210 mini tractor is designed for farm work, garden plots, dachas, and municipal services. This unit combines a diesel engine with 4x4 all-wheel drive, ensuring high cross-country capability and a long service life under intensive use.
Key Advantages:
- Reliable 21 hp diesel engine, guaranteeing economical fuel consumption and sufficient traction for attachments.
- 4x4 all-wheel drive and mechanical rear differential lock for confident operation on slippery or uneven terrain.
- Multi-stage 14+8 gearbox provides a wide range of speeds for agricultural and transport operations.
- Compact dimensions: length 2700 mm, width 1150 mm, height 1900 mm, and a minimum turning radius of 2.7 m make the tractor maneuverable in confined spaces.
Below is a detailed table of technical specifications, which includes all the main parameters of the Yanmar F-210 model:
| Engine power, hp: | 21 |
| Wheel formula: | 4x4 |
| Engine type: | diesel |
| Number of cylinders: | 3 |
| Fuel tank capacity, L: | 20 |
| Gearbox: | 14+8 |
| Max travel speed, km/h: | 23 |
| Differential lock: | mechanical, rear axle |
| Brakes: | drum brake |
| Overall length, mm: | 2700 |
| Overall width, mm: | 1150 |
| Overall height, mm: | 1900 |
| Front wheel size: | 6-12 |
| Rear wheel size: | 8.3-24 |
| Minimum turning radius, m: | 2.7 |
| Lifting capacity of lifting mechanism, kg: | 750 |
| PTO speed, rpm: | 540/780/1200 |
| Weight, kg: | 870 |
The Yanmar F-210 is equipped with a three-cylinder diesel engine that ensures reliable operation under various loads and reduced fuel consumption. The 20 L fuel tank capacity allows for long operations without frequent refueling. The model features drum brakes for stable braking, and the mechanical rear differential lock enhances cross-country capability on difficult terrain and when working with trailed or mounted equipment.
The 14+8 gearbox allows selecting the optimal driving and traction mode for soil cultivation, working with plows, tillers, mowers, and other implements. A maximum travel speed of up to 23 km/h is sufficient for transport between fields and on roads. A lifting capacity of 750 kg makes this mini tractor a versatile solution for many types of work in farming and the municipal sector.
A total weight of 870 kg ensures good stability during operation, while compact dimensions and a small turning radius make the Yanmar F-210 ideal for working in gardens, complexes with narrow passages, and small plots. The manufacturer Yanmar is known for its engineering prowess and equipment durability — this model confirms these standards.
The Yanmar F-210 mini tractor is a practical choice for those seeking a balance between compactness and functionality: versatile for agricultural work, landscape maintenance, and municipal services.
