LOVOL FT244HX Mini Tractor — A Reliable Assistant for Your Farm
The LOVOL FT244HX mini tractor from manufacturer Lovol Heavy Industry Co., LTD is a versatile and compact professional machine with 24 hp (17.6 kW) power, designed for efficient work in agriculture, utilities, and construction sites. The heart of the machine is a three-cylinder diesel engine, model KM385BT, with a displacement of 1532 cm3, direct injection, and liquid cooling, ensuring reliable and economical operation with fuel consumption up to 244 g/(kW*h).
Key Advantages and Design Features
The FT244HX features 4x4 all-wheel drive with a connectable front axle drive, adjustable track width, and power steering (GUR), guaranteeing excellent off-road capability and maneuverability. The chassis design and classic hitch allow for the use of a wide range of mounted and trailed equipment compatible with Chinese and Ukrainian originals, as well as standard adapters.
Functional Capabilities
The LOVOL FT244HX is suitable for performing a variety of operations on the farm:
- sowing and harvesting;
- soil cultivation and preparation;
- inter-row care and plant maintenance in gardens and fields;
- grass mowing, hay and fodder harvesting;
- cargo transportation and utility work.
The mini tractor's configuration ensures convenient and safe operation: mechanical stepped gearbox with reverse (8 forward / 2 reverse), dry reinforced single-disc clutch, brake drums on the rear wheels with separate brake pedals, rear semi-independent PTO with speeds of 540 / 1000 rpm and 6 splines with a diameter of 35 mm.
Universal technical characteristics make the FT244HX suitable for cultivating plots of 2 hectares or more, and its structural weight of 1360 kg, combined with optimal ground clearance (agrotechnical 360 mm, clearance 290 mm), allows for work on difficult terrain. Minimum turning radius: 3.0 m with one pedal depressed and 3.75 m without using it.
Recommended similar models and analogs: Jinma 404, Shifeng 354, Dongfeng, Xingtai, Foton, Zoomlion, DTZ 5244NRX, Bulat 454, Bulat 250, Bulat 254, Belarus 320.4, Mini Tractor Shifeng, DW 244, DTZ 5404K, Solis 26 Tractor.
It is best to purchase from an official representative — Flash Army agricultural machinery store, which provides free delivery in Kyiv and the region and ships equipment to other regions of Ukraine. For detailed consultation on selecting attachments and purchase conditions, please contact Flash Army representatives.
Technical Specifications:
| Model Information | |
|---|---|
| Model Information | Foton Lovol FT244HX |
| Tractor Type | Universal row-crop wheeled tractor |
| Tractor Traction Class | 0.6 |
| Manufacturer | Lovol Heavy Industry Co., LTD |
| Country of Manufacture | China (PRC) |
| Wheel Formula | 4x4, with connectable front axle drive |
| Engine Technical Specifications | |
| Engine Type | Three-cylinder diesel, four-stroke, with direct fuel injection, non-turbocharged, liquid-cooled |
| Engine Model | KM385BT |
| Engine Displacement, cm3 | 1532 cm3 |
| Engine Power, hp and kW | 24 hp or 17.6 kW |
| Number of Engine Cylinders | 3 |
| Cylinder Diameter | 85 mm |
| Piston Stroke | 90 mm |
| Fuel Consumption | up to 244 g/(kW*h) |
| Overall Dimensions, mm | |
| Wheelbase, mm | 1670 mm |
| Overall Dimensions, mm | 3240x1350x1850 mm |
| Front Wheel Track, mm | 1280, 1380 mm |
| Rear Wheel Track, mm | 1080, 1160, 1260 mm |
| Agrotechnical Ground Clearance, mm | 360 mm |
| Clearance, mm | 290 mm |
| Minimum Turning Radius, m | 3.0 meters with one brake pedal depressed 3.75 meters without depressing the brake pedal |
| Structural Weight, kg | 1360 kg |
| Gearbox (КПП) | |
| Gearbox Type | Mechanical, stepped, with reverse |
| Number of Gears (forward / reverse) | 8 forward / 2 reverse |
| Clutch | Dry reinforced single-disc clutch |
| Brake System | |
| Brake System Type and Design | Brake drums, dry type, on rear wheels. Separate brake pedals |
| Power Take-Off (PTO) | |
| PTO Type | Rear semi-independent |
| PTO Rotation Speed, rpm | 540 - 1000 rpm |
| Number of Splines + PTO Diameter | 6 splines, 35 mm diameter |
| Electrical System (Electrosystem) | |
| On-board Electrical System Voltage, V | 12 V |
| Travel Speed, km/h | |
| Maximum Speed, km / h | Forward: 1.71-25.76 km / h Reverse: 2.23-10.29 km / h |
| Configuration | |
| Front Wheel Size | 6.50 - 16 |
| Rear Wheel Size | 11.2 - 24 |
| Other Characteristics | |
| Engine Oil Volume, L | 5 L |
| Engine Cooling System Volume, L | 10 L |
| Fuel Tank Volume, L | 29 L |
| Transmission Oil Volume, L | 15 L |
| Front Axle Oil Volume, L | 3.5 L |
| Hydraulic Tank Oil Volume, L | 9.5 L |
The LOVOL FT244HX combines a balance of power, compactness, and versatility: a 1532 cm3 engine, 3 cylinders, a wide range of gears, and a reliable transmission ensure long-term operation and high productivity in the field and on plots with difficult terrain. Model information: Foton Lovol FT244HX. Tractor type: Universal row-crop wheeled tractor. Manufacturer: Lovol Heavy Industry Co., LTD. Country of manufacture: China (PRC). More detailed consultation and purchase conditions can be obtained from Flash Army representatives by phone, as indicated on the website.
