The KATA KE 354 mini-tractor from the manufacturer KATA is a reliable and versatile mini-tractor in the Tractors > Mini-tractors category, designed for a wide range of agricultural, municipal, and transport tasks. The design and technical specifications of the KATA KE 354 model make it an effective solution for owners of small farms, agricultural enterprises, and service teams. The model belongs to the product line: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mini-tractors.
Key Technical Specifications
The KATA KE 354 is equipped with a 4L22BT 4-stroke diesel engine with a power output of 35 hp (25.7 kW), a displacement of 2160 cm3, and four vertically arranged cylinders. The starting system is an electric starter. Cooling is liquid, closed, with forced circulation of coolant, and the fan is driven by a V-belt transmission. The nominal fuel consumption is ≤235 g/kWh, and the nominal crankshaft speed is 2350 rpm.
Traction and transmission characteristics include a nominal traction force of 7.4 kN, a (4+4)x2 gearbox with rear differential lock. The clutch is a dry, 2-disc, constantly closed type, and the main drive is direct. Steering is hydraulic, and the brakes are located on the secondary shaft of the gearbox with brake drums, ensuring reliable braking under load.
The power take-off system features a rear spline PTO with operating speeds of 540 / 1000 rpm, making the tractor versatile for connecting various mounted and trailed equipment. The hydraulic system pump type is a gear pump (NSH) for implement drive and an NSH for power steering operation. The maximum lifting capacity of the hitch mechanism is 670 kg, and the number of hydraulic outlets is 2.
Tires: front — 6.50-16, rear — 11.2-24. Wheel track: front — 1205 mm, rear — 1244-1425 mm. The tractor is equipped with a trailer connector (socket) — +, and a compressor — +. The curb weight of the machine is 1780 kg. Dimensions (LxWxH): 3420x1630x2230 mm.
Technical Specifications (Summary Table)
| Engine power, hp (kW) | 35(25.7) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, 4L22BT |
| Number and arrangement of cylinders | 4, vertical |
| Engine starting system | electric starter |
| Cooling system | liquid, closed, with forced coolant circulation |
| Cooling system fan drive | V-belt transmission |
| Engine displacement, cm3 | 2160 |
| Nominal engine fuel consumption, g/kWh | ≤235 |
| Nominal engine crankshaft speed, rpm | 2350 |
| Nominal traction force, kN | 7.4 |
| Gearbox (КП) | (4+4)x2 |
| Rear differential lock | + |
| Clutch | dry, 2-disc, constantly closed type |
| Main drive | direct |
| Steering | hydraulic |
| Brakes | on secondary gearbox shaft, brake drums |
| Power Take-Off (PTO) | rear, spline |
| Hydraulic system pump type | gear pump (NSH) for implement drive / NSH for power steering operation |
| Power Take-Off (PTO) speed, rpm | 540 / 1000 |
| Maximum lifting capacity of hitch mechanism, kg | 670 |
| Tire size | front 6.50-16, rear 11.2-24 |
| Wheel track | front 1205 mm, rear 1244-1425 mm |
| Number of hydraulic outlets | 2 |
| Trailer connector (socket) | + |
| Compressor | + |
| Curb weight, kg | 1780 |
| Dimensions LxWxH, mm | 3420x1630x2230 |
Advantages and Application
The KATA KE 354 combines the fuel efficiency of a diesel engine, a well-designed transmission, and reliable hydraulics, allowing it to perform plowing, soil cultivation, seeding, cargo transportation, and work with mounted equipment. The presence of a PTO with two speed modes (540/1000) makes the tractor versatile for connecting a wide range of agricultural implements. Hydraulic steering and sufficient hitch lifting capacity increase comfort and productivity. This model is optimal for those who need combined maneuverability, reliability, and ease of operation for daily tasks in the field and on the farm.
