Faighter TY-254 Reverse Mini Tractor
The Faighter TY-254 Reverse mini tractor is a compact and durable assistant for private households, municipal services, and small farms. This model from the manufacturer Faighter combines a powerful 3-cylinder KM385 diesel engine (1532 cm3 displacement) with high cross-country capability thanks to 4x4 all-wheel drive and rear differential lock. Its 24 hp (17.6 kW) power ensures reliable operation with various mounted and trailed equipment in the field, garden, or greenhouse.
Key Advantages of the Model
- 24 hp (17.6 kW) power for efficient performance of agricultural and municipal tasks.
- KM385 3-cylinder diesel engine (1532 cm3) — an economical and durable unit with a nominal speed of 2350 rpm.
- 4x4 wheel formula and rear differential lock enhance cross-country capability on difficult terrain and slopes.
- Mechanical gearbox (4+4)x2 with reverse allows for precise maneuvering and work in confined spaces.
- Dry dual-disc clutch and power steering reduce operator fatigue and simplify control.
Technical Specifications
| Engine power, hp (kW) | 24 (17.6) |
| Wheel formula | 4x4 |
| Engine type | 3 cylinders, KM385 diesel engine |
| Engine displacement, cm3 | 1532 |
| Nominal fuel consumption g / kWh | 275 |
| Nominal crankshaft speed rpm | 2350 |
| Nominal traction force kN | 4.7 |
| Gearbox | mechanical (4+4)x2 |
| Rear differential lock | Yes |
| Clutch | Dry, dual-disc |
| Power steering | Yes |
| Brake mechanism | drum type |
| Power take-off (PTO) speed rpm | 540/1000 |
| Maximum lifting capacity of mounted mechanism, kg | 680 |
| Wheelbase, mm | 1730 |
| Front wheel track, mm | 1220, 1440 |
| Rear wheel track, mm | 1120 - 1450 |
| Front tire size | 7.5-16 |
| Rear tire size | 11.2-24 |
| Theoretical forward speed, km / h | 32.19 |
| Theoretical reverse speed, km / h | 7.75 |
| Fuel tank volume L | 20 |
| Overall dimensions (LxWxH), mm | 3400x1465x1980 |
| Structural weight, kg | 1450 |
Compact dimensions (3400x1465x1980 mm) combined with a structural weight of 1450 kg make the TY-254 Reverse convenient for working in greenhouses, narrow rows, gardens, and for municipal tasks. The 20 L fuel tank provides long autonomy without frequent refueling, and a theoretical forward speed of up to 32.19 km/h allows the tractor to be used for transporting goods over short distances.
Two PTO modes (540/1000 rpm) make the tractor compatible with a wide range of mounted and trailed equipment, and the maximum lifting capacity of the mounted mechanism up to 680 kg allows for most typical agricultural operations. Drum brakes and a dry dual-disc clutch mechanism ensure reliable operation with regular maintenance.
The mini tractor is suitable for cultivating small and medium-sized plots, working in greenhouse farms, horticulture, municipal services, and for transporting goods within the farm. If you need additional accessories or advice on selecting mounted equipment, please contact official Faighter dealers.
Manufacturer: Faighter. Category: Tractors > Mini Tractors. Configuration and technical parameters comply with the specification provided above.
