FPV Drone 13" with Fiber Optic "ASTRALEXPRESS" 20km without Battery (without Warhead)

Brand: Astral Express. Category: Drones & Quadcopters > FPV Drones. This lightweight yet durable FPV drone "RAPTOR 13" from ASTRALEXPRESS is designed for long missions with video transmission via fiber optic cable up to 20 km. The product name states: without battery (without warhead), however, the full list of components includes batteries, so please check the package contents carefully when ordering.

Key Advantages

• Proprietary Ukrainian production — guarantees quality and prompt technical support;
• Powerful electronics based on F722 stack and 60A ESCs ensure stable and precise control;
• Caddx Ratel Pro camera provides clear images day and night, enhancing reconnaissance and recording efficiency;
• Modular frame design allows for quick maintenance and component replacement, reducing downtime.

FPV Specifications

• Fiber optic reel: 20 km;
• Payload: up to 2.5 kg;
• Flight speed, km/h: cruising — 60–70; maximum — 115;
• Maximum flight duration: up to 22 min.

Dimensions

• length – 480 mm (equipped 750 mm);
• width – 480 mm (equipped 750 mm);
• height – 50 mm (equipped 300 mm).

ASTRALEXPRESS Fiber Optic Reel Specifications

• Reel length: 20 km;
• Fiber type: single-mode G657a2, 0.25 mm;
• Video protocol: PAL / NTSC;
• Control protocol: CRSF;
• Operating wavelength: 1310 / 1550 nm;
• Reel weight and dimensions: 20 km — 1.85 kg; 370×140 mm.

Package Contents

• Carbon frame: 13" inches;
• Flight controller: F722 V2 Flight Controller Aocoda;
• Motor speed controller: ESC M4 8S/80A/32BIT;
• Power distribution board: Current Regulators Aocoda;
• Camera: Caddx Ratel Pro;
• Motors: 4215/480KV Top Motor;
• Propeller set: HQProp 13x9x3;
• Battery: 8s3p 15000mAh - 2 pcs.;
• Straps;
• Fiber optic reel (20km) ASTRALEXPRESS;
• Packaging.

The FPV drone 13" ASTRALEXPRESS "RAPTOR 13" combines a reliable design, high-performance components, and the ability to transmit video over long distances via single-mode fiber. This model is suitable for professional tasks requiring stable data transmission and precise motion control with minimal risk of signal loss. Note the modular design — it significantly simplifies field maintenance and component replacement. For full deployment of the complex, we recommend additionally purchasing a ground control unit, which will allow for the formation of a complete system for long-term observations and video stream transmission.
