RunCam Wasp Nano FPV Camera

RunCam Wasp Nano (Digital) — a compact, high-performance HD camera for FPV flights from the RunCam brand. This camera is part of the DJI FPV digital video system and pairs well with the RunCam Link video transmitter, providing a clear image and smooth video transmission during dynamic flights.
The RunCam Wasp Nano is designed for pilots who value low weight and high video quality: it transmits 720P at 120 frames per second with a bitrate of up to 50 Mbps and a 4:3 aspect ratio, delivering a smooth picture and good motion detail.

Advantages and Compatibility

The camera is optimized for digital FPV systems and works in conjunction with RunCam Link, allowing for low-latency video transmission — a low-latency mode of up to 28 ms. Its light weight and compact dimensions make it ideal for lightweight frames and racing drones, where mass and aerodynamics are important.

Key Features

• Sensor: 1/3 inch
• Extended field of view up to 160° FOV
• Supports 120 fps, 50 Mbps, 4:3 aspect ratio
• Low-latency mode — up to 28 ms
• Differences from previous models: 155° FOV

Wasp Nano Camera Technical Specifications

• Sensor: 1/3 inch
• Lens: FOV H: 160° V: 127° D: 92°
• Coaxial cable: 80 mm
• Dimensions: L18x W14x H18 mm
• Shutter type: Rolling shutter
• Weight: 6 g (with cable)
• Resolution: 720P at 120 fps (4:3)

The RunCam Wasp Nano camera stands out for its compactness and functionality: small dimensions (L18×W14×H18 mm) combined with a weight of only 6 g (with cable) allow it to be installed even on the smallest and fastest frames. The 80 mm coaxial cable simplifies connection to the video transmitter, and the rolling shutter is well-suited for most FPV applications. Thanks to its wide field of view and high frame rate, the camera provides comfortable spatial orientation during races and tricks.

RunCam — a renowned manufacturer in the FPV equipment sector, and the Wasp Nano model confirms the company's focus on image quality and technical reliability. If you need a digital camera with low latency, high frame rate, and a wide field of view for compatibility with DJI FPV and the RunCam Link system, the Wasp Nano — is an excellent choice.
