Yagi Antenna 680-880 MHz for FPV Drones - Reliable Long-Range Communication SKYNOVA
The Yagi antenna is a highly effective solution for controlling FPV drones from a mast or repeater. It operates in the 735/750/915/960 MHz frequency range, providing a powerful 15dBi gain. This minimizes signal loss and improves stability over long distances.
The antenna is made of durable aluminum, ensuring structural longevity, and the SMA connector guarantees convenient connection. Thanks to linear polarization and a 36° beamwidth, optimal signal transmission and reception quality are achieved.
Key advantages:
✅ Powerful 15dBi gain for long-range communication
✅ Reliable aluminum construction
✅ Optimal operating range 680-880 MHz at VSWR 1.2
✅ Linear polarization for stable transmission
Specifications:
- Gain: 15dBi
- VSWR: 1.1
- Impedance: 50 Ohm
- Beamwidth: 70° × 36°
- Polarization: Linear
- Number of directors: 10 pcs.
- Connector: SMA
- Material: Aluminum
- Dimensions: 1250 × 300 × 300 mm
- Max input power: up to 250 W
