WUZHENG TS504 Tractor
The WUZHENG TS504 is a modern mini-tractor from the WUZHENG brand (PRC), combining reliability, high productivity, and operator comfort. The TS504 model is built on the experience of previous developments and the application of modern machine-building technologies. Thanks to its air-conditioned cabin, this tractor is suitable for agricultural, municipal, and industrial work where operator protection and ease of operation are important.
Key Advantages and Purpose
The TS504 features 4x4 all-wheel drive, ensuring excellent cross-country capability on various terrains. Compact dimensions of 3848×1705×2550 mm and a ground clearance of 430 mm facilitate maneuvering in confined spaces. A stable working platform is provided by a front track width of 1270 mm and a rear track width of 1320 mm, while tire sizes of 8.3-20 at the front and 12.4-28 at the rear ensure reliable grip.
The powerful and economical power unit is a ChangChai CC4G33T engine with 50 hp (36.75 kW), four vertical cylinders, water cooling, and turbocharging. The maximum torque is 183 N·m at 2400 rpm, with a specific fuel consumption of 250 g/kWh. The 70-liter fuel tank ensures long autonomous operation without frequent refueling.
Versatility of Attachments
The TS504 is equipped with a power take-off (PTO) shaft with speeds of 540/1000 rpm, allowing for the connection of a wide range of mounted and trailed equipment. A traction force of 9.3 kN and two pairs of hydraulic outlets simplify work with plows, harrows, seeders, mowers, and other implements.
We also recommend reviewing other mini-tractor models, such as Jinma 404, Shifeng 354, Dongfeng, Xingtai, Foton, Zoomlion, DTZ 5244NRX, Bulat 454, Bulat 250, Bulat 254, Belarus 320.4, Minitractor Shifeng, DW 244, DTZ 5404K, Solis 26 tractor — to compare technical specifications and choose the optimal machine for your tasks.
How to Purchase
Want to buy the WUZHENG TS504? Place an order on the website, and a representative from Flash Army's sales department will contact you to provide detailed information on availability, price, delivery, and operating conditions. Our specialists will help you choose the optimal configuration and answer all technical questions regarding this model.
Technical Specifications
| Wheel formula | 4*4 |
| Model | CC4G33T |
| Number of cylinders | 4 |
| Displacement | 3.26 |
| Type | Vertical, water-cooled, four-stroke with turbocharging |
| Rated power kW (hp) | 36.75 (50) |
| Torque, N-m / Rated RPM, rpm | 183/2400 |
| Specific fuel consumption, g / kWh | 250 |
| Fuel tank capacity, L | 70 |
| Travel speed (km / h) | 2.59-29.86 |
| PTO rpm. | 540/1000 |
| Traction force (kN) | 9.3 |
| Hydraulic outlets, number of pairs, pcs. | 2 |
| Overall dimensions, (LxWxH), mm | 3848*1705*2550 |
| Tire size | 8.3-20, 12.4-28 |
| Front wheel track width | 1270 |
| Rear wheel track width | 1320 |
| Ground clearance, mm | 430 |
| Weight, kg | 2180 |
| Front counterweights (kg) | 145 |
| Rear counterweights (kg) | 90 |
| Air conditioner | + |
The WUZHENG TS504 model has proven itself as a reliable assistant for farmers and utility services: the versatility of attachments, a powerful and economical engine, a comfortable cabin, and air conditioning make this equipment a profitable investment in terms of price-quality ratio. The manufacturer WUZHENG ensures high assembly quality and service availability. Brand: WUZHENG. Category: Tractors > Mini Tractors.
