Xingtai T240 TPK Mini Tractor — A Reliable and Affordable Assistant for Your Farm
The Xingtai T240 TPK mini tractor from Xingtai Tractor Manufacturing Co., LTD combines ease of use, durability, and an attractive price. This model is designed for cultivating small plots up to several hectares, where large specialized equipment is impractical due to size or cost. Compact yet powerful, this unit is suitable for private farms, municipal services, and construction work, offering versatility through the ability to connect various attachments.
Purpose, Reviews, and Operational Capabilities
Users note that the Xingtai T240 TPK successfully performs a wide range of tasks: preparing soil for sowing, planting and harvesting crops, mowing and fodder preparation, transporting goods, and clearing leaves and snow. With additional attachments, the mini tractor transforms into a multifunctional unit for the farm. Purchasing through authorized dealers guarantees the best price and an official manufacturer's warranty.
Key Technical Specifications and Design Features
The factory configuration of the Xingtai T240 TPK includes a four-stroke diesel engine with direct fuel injection, without turbocharging, and with a liquid cooling system. This is a three-cylinder unit that ensures stable operation under load. The nominal engine power is 24 hp (17.6 kW), with a displacement of 1532 cm3. For effective maneuvering, a mechanical gearbox with high and low ranges is used; the promotional description states 6 forward gears and 2 reverse gears, while the technical block indicates (3+1)x2, which also provides flexible speed selection.
The drive system is 4x2; the clutch is a single-disc dry type. The power take-off shaft operates at 540 rpm. The wheel formula and tire type allow the tractor to be operated on various soils: front wheels 5.00x14 (agricultural road-type tires), rear wheels 7.50x20. Technical fluid capacities are as follows: engine oil — 5 L, cooling system — 10 L, fuel tank — 20 L.
Advantages of the Model
- Compact dimensions and 320 mm ground clearance — convenient for working in rows and confined areas.
- Reliable three-cylinder diesel engine with liquid cooling.
- Ability to connect various attachments for versatile use.
- Affordable cost compared to large-sized equipment, making the model attractive for small and medium-sized farms.
Detailed technical parameters:
| Engine Type | Three-cylinder diesel, four-stroke, with direct fuel injection, non-turbocharged, liquid-cooled |
| Engine Displacement, cm3 | 1532 cm3 |
| Engine Power, hp and kW | 24 hp or 17.6 kW |
| Number of Engine Cylinders | 3 |
| Cylinder Diameter | 85 mm |
| Piston Stroke | 90 mm |
| Engine Dimensions, mm | 569x525x604 mm |
| Engine Structural Weight, kg | 234 kg |
| Wheelbase, mm | 1520 mm |
| Overall Dimensions, mm | 2870x1190x1920 mm |
| Front Wheel Track, mm | 1070 mm |
| Rear Wheel Track, mm | 990 mm |
| Ground Clearance, mm | 320 mm |
| Drive Type | 4x2 |
| Transmission Type | Mechanical, non-synchronized |
| Number of Gears (forward / reverse) | (3+1)x2 (also stated as 6 forward / 2 reverse in text) |
| Clutch | Single-disc dry |
| Power Take-Off, rpm | 540 |
| Front Wheel Size | 5.00x14 (agricultural road-type tires) |
| Rear Wheel Size | 7.50x20 |
| Engine Oil Capacity, L | 5 |
| Engine Cooling System Capacity, L | 10 |
| Fuel Tank Capacity, L | 20 |
Flash Army online store has been importing Xingtai equipment for many years and offers the Xingtai T240 TPK model as one of the budget-friendly and reliable options for small and medium-sized farms. To guarantee the best price and an official manufacturer's warranty, please contact authorized sellers.
