Changfa CFH1604A Tractor — a reliable mototractor for professional work

The Changfa CFH1604A tractor from the Changfa brand is a practical and economical solution in the category: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mototractors. The model is designed for a wide range of agricultural and transport tasks on fertile and heavy soils, ensuring high productivity, structural durability, and operator comfort at a moderate price compared to imported counterparts.

At the heart of the CFH1604A is a powerful six-cylinder Yuchai YC6J90-T301 Euro III engine with turbocharging, intercooler, and pre-start heating. The engine is equipped with an ultra-efficient two-stage air filter and a three-level fuel filtration system for enhanced reliability. Thanks to the application of German technologies, the torque reserve has been increased by 33%, and the electronic power management system allows for optimized fuel consumption and flexible adjustment of operating parameters.

A capacious 220 L fuel tank ensures long continuous operation in the field. Power transmission is realized through a reversible transmission with a creeper gear and synchronizers, making control smooth and convenient; the maximum tractor speed is 36 km/h. The CFH1604A easily aggregates with a large number of attachments thanks to a powerful hydraulic system and electronic hitch control, expanding its utility on the farm.

The tractor's frame and chassis are rigidly constructed with reinforced axles, guaranteeing reliable operation under heavy loads. The cabin is sealed and comfortable: it features heating and air conditioning systems, cabin filters, a roof hatch, an engine operating mode switch, and a rear-view camera with a monitor for increased safety and operator convenience.

Advantages of Changfa CFH1604A

  • High productivity thanks to a powerful six-cylinder Yuchai engine with electronic power management;
  • Three-level fuel filtration system and ultra-efficient two-stage air filter for long-term and reliable operation;
  • Large 220 L fuel tank for long work shifts without refueling;
  • Comfortable sealed cabin with heating, air conditioning, cabin filters, hatch, and video camera for safe operator work;
  • Wide aggregation possibilities thanks to a powerful hydraulic system and electronic hitch control;
  • Robust rigid chassis with reinforced axles and wet disc brakes.

How to order

You can buy the Changfa CFH1604A tractor in Ukraine at the "Flash Army" online store. We work directly with the manufacturer, so we offer a favorable price, full warranty support, and service. To place an order, fill out the form on the website — our managers will contact you to clarify details and arrange delivery to all regions of the country.

Technical Specifications

Technical Specifications:

Engine typeYuchai YC6J90-T301 Euro III with turbocharger, intercooler, pre-start heating
Engine power, hp (kW)117.5 (160)
Air filterUltra-efficient 2-stage air cleaner (Luxurious)
Clutch14-inch LUK dual-action clutch, single-disc with hydraulic drive
TransmissionWith synchronizer and creeper gear: 32 forward + 32 reverse
Hydraulic system: type / number of hydraulic outletsSeparate / 3 pairs
Hydraulic pump typeGear pump with engine drive
Hitch controlRexroth electronic system (Germany)
PTO: power, hp / kW143 / 105.3
PTO damperHydraulic with energy accumulator
PTO: revolutions, rpm540/1000
Number of PTO splines8-48x40x8 (base) / option 8-38x29.4x6 or 6-34.8x28.9x8.7
Hitch lifting capacity, kg4500
Hydraulic system flow rate, l/min52
Rear differential lockHydraulic
Front / rear wheel track, mm1736 / 1656-2588
SteeringHydraulic, independent
Front / rear tire size, inch14.9-28 / 18.4-38
Turning radius, m5.4
Ground clearance, mm490
Overall dimensions: LxWxH, mm5100×2390×2970
Wheelbase, mm2680
Curb weight, kg5350
Ballasting: front / wheel counterweights, kg640 / 600
BrakesDisc, wet, with hydraulic drive
Fuel tank capacity, L220
Cabin equipmentSealed cabin with heating and air conditioning system, cabin filters, roof hatch, engine operating mode switch, rear-view camera with monitor

The "Flash Army" online store provides delivery throughout Ukraine, service support, and the opportunity to purchase the Changfa CFH1604A tractor at a favorable price directly from the manufacturer.
