Tractor SKAUT TV-804S — overview and technical specifications
The SKAUT TV-804S tractor from the Skaut brand — is a powerful universal machine in the mototractor class, designed for heavy field, construction, and municipal work. The model combines a reliable diesel engine, a robust transmission, and efficient hydraulics, making it an optimal solution for farms and enterprises that require durable equipment with a wide range of basic options.
Key data
Brand: Skaut
Model: Tractor SKAUT TV-804S
Class: Tractors, Mototractors category
Purpose: universal operation for agricultural and utility work
Engine and performance
Engine power is 80 hp (58.8 kW). Engine type: diesel, 4-stroke, model Laidong KM4100ZT4-53 (Stage II). Four cylinders, vertical arrangement. Engine displacement — 3299 cm3. Starting system — electric starter. Cooling system — liquid, closed, with forced circulation of coolant. Nominal engine fuel consumption — ≤225 g/kWh. Nominal traction force — 13.9 kN.
Transmission and chassis
The gearbox has 12+12 gears, with rear differential lock. Clutch — dry 2-disc constantly closed type. Main drive — direct. Wheel formula — 4x4, steering — hydraulic. Brakes are located on the secondary shaft of the gearbox and are designed as brake drums.
Power Take-Off (PTO) and hydraulics
PTO — rear, splined, PTO shaft speed — 540 / 1000 rpm. Hydraulic system pump type: gear pump for hitch drive and gear pump for power steering operation. Lifting capacity of the hitch mechanism — 1880 kg. Number of hydraulic outlets — 2. Trailer connector (socket) is present.
Dimensions, weight, and tires
Wheel track: front — 1440 mm, rear — 1310 mm. Tire size: front — 9.5-24, rear — 14.9-30. Ground clearance — 390 mm. Dimensions (LxWxH) — 3950x1780x2710 mm. Operating weight of the tractor — 2950 kg.
Below are the structured technical specifications for easy reference:
| Engine power, hp (kW) | 80 (58.8) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, Laidong KM4100ZT4-53 (Stage II) |
| Number and arrangement of cylinders | 4, vertical |
| Engine starting system | electric starter |
| Cooling system | liquid, closed, with forced circulation of coolant |
| Engine displacement, cm3 | 3299 |
| Nominal engine fuel consumption, g/kWh | ≤225 |
| Nominal traction force, kN | 13.9 |
| Gearbox (КП) | 12+12 |
| Rear differential lock | + |
| Clutch | dry 2-disc constantly closed type |
| Main drive | direct |
| Steering | hydraulic |
| Brakes | on the secondary shaft of the gearbox, brake drums |
| Power Take-Off (PTO) | rear, splined |
| Hydraulic system pump type | gear pump for hitch drive / gear pump for power steering operation |
| Hitch lifting capacity | 1880 kg |
| Power Take-Off (PTO) speed, rpm | 540 / 1000 |
| Wheel track | front 1440, rear 1310 |
| Tire size | front 9.5-24, rear 14.9-30 |
| Ground clearance, mm | 390 |
| Number of hydraulic outlets | 2 |
| Trailer connector (socket) | + |
| Dimensions LxWxH mm | 3950x1780x2710 |
| Operating weight, kg | 2950 |
The SKAUT TV-804S tractor — is a reliable choice for those seeking powerful and durable equipment with a full set of basic options: an efficient engine, robust transmission, PTO mechanisms, and powerful hydraulics for working with a wide range of attachments. Thanks to the specified technical characteristics, the tractor is ideal for plowing, cultivation, cargo transportation, loader operation, soil tillage, and other agricultural tasks where reliability and durability are required.
Brand: Skaut. Category: Tractors > Mototractors.
