Matek H743-WLITE Flight Controller

Matek H743-WLITE — a high-performance flight controller designed for fixed-wing aircraft and VTOL systems. This controller combines a powerful processor, precise sensors, and extensive connectivity options, making it an excellent choice for both professional projects and amateur models.

Brief Overview

Brand: Matek.
Product Type: Drones & Quadcopters > Stacks (FC+ESC).

Key Features

• Processor: STM32H743VI (480 MHz)
• Gyroscope & Accelerometer: MPU6000 (SPI)
• Barometer: DPS310 (I2C)
• Memory: 32 Mbit flash memory for Blackbox
• Integrated OSD: BetaFlight OSD (MAX7456E)
• UART Ports: 6 x UART
• PWM Outputs: 12 channels
• Inputs: PPM, SBUS, DSM, CRSF
• Input Voltage: 7-36V (2-8S LiPo)
• Firmware Support: ArduPilot, iNav
• Dimensions: 57 x 27 mm
• Weight: approximately 14 g

Product Description

Matek H743-WLITE is designed for pilots and developers who require a reliable and high-speed controller for complex fixed-wing aircraft and VTOLs. Thanks to the powerful STM32H743VI processor with a frequency of 480 MHz, the controller ensures real-time processing of a large volume of telemetry and control commands, guaranteeing stable autopilot operation and precise flight stabilization.

Integrated MPU6000 sensors (gyroscope and accelerometer) and a DPS310 barometer provide accurate orientation and altitude data necessary for complex maneuvers and stabilization. The presence of 6 UART serial ports allows for connecting GPS, telemetry modules, additional sensors, and radio receivers without limitations, while 12 PWM channels enable control of numerous servos, rudders, and motors on multi-axis or hybrid platforms.

The built-in OSD based on MAX7456E (BetaFlight OSD) displays essential flight information directly in the video feed: speed, altitude, flight modes, and other critical data, enhancing safety and ease of operation. 32 Mbit of flash memory for Blackbox allows recording flight parameters for subsequent analysis, PID tuning, and optimization of aircraft behavior.

The controller supports popular ArduPilot and iNav firmwares, offering flexibility in choosing functionality, autopilot setup, and integration with various types of aircraft. The input voltage of 7-36V (2-8S LiPo) ensures compatibility with a wide range of power sources, and the compact dimensions of 57 × 27 mm and weight of approximately 14 g allow for easy integration of the board into the nose section of fixed-wing and VTOL models without excessive load.

Advantages of Matek H743-WLITE

• Powerful Performance: high-frequency processor and reliable sensors for stable and precise flight;
• Extensive Connectivity: six UART ports and 12 PWM outputs for hardware expansion and peripheral connection;
• Flexible Configuration: compatibility with ArduPilot and iNav for adaptation to various aircraft types and missions;
• Ease of Use: built-in OSD and support for PPM/SBUS/DSM/CRSF simplify system integration and setup.

Package Contents

• Matek H743-WLITE Flight Controller
• Set of cables and connectors
• User Manual

This controller is ideal for those building complex fixed-wing aircraft or VTOL systems who require a reliable and functional solution with extensive connectivity, built-in OSD, and support for leading firmwares. Thanks to its detailed connectivity options, compact dimensions, and light weight, the Matek H743-WLITE easily integrates into various designs, providing stable and predictable flight control.
