FPV Goggles Walksnail Avatar Digital HD FPV Goggles w/ Antennas — Walksnail Avatar HD
Walksnail Avatar HD — modern digital FPV goggles for drone pilots seeking a high-quality alternative to classic models. This model features a pair of Full HD OLED displays with a resolution of 1920×1080 (1080p) and a screen size of 0.49 inches, providing a wide 46° field of view and smooth visuals at a 1080/100 Hz refresh rate, supporting up to 120 frames per second for maximum motion clarity.
The goggles operate on a new video transmission protocol from Walksnail, ensuring long signal range and stable transmission in the 5.725–5.850 GHz frequency band. Important: this model is not compatible with analog video systems and not compatible with the DJI FPV digital system.
Features include a built-in HD DVR for flight recording, an HDMI output for connecting external sources, Betaflight Canvas support for displaying telemetry and other data on screen, and a Ranging mode for measuring distance to the drone. The kit includes 4 antennas, enhancing reception quality and operating range.
| Specifications | Description |
|---|---|
| Model | Walksnail Avatar HD |
| Screen Type | OLED |
| Resolution | 1920×1080 (1080p) |
| Video Transmission Protocol | New Walksnail protocol |
| Functional Features | Betaflight Canvas support, built-in HD DVR, HDMI output |
| Antennas | 4 antennas (included) |
| Focus Adjustment | From +2 to -6 diopters, no corrective lenses needed |
| Interpupillary Distance (IPD) | 58 - 70 mm (mechanical range), 54 - 74 mm (visual range) |
| Ventilation | Adjustable, anti-fog |
| Power | Power button |
| Input Voltage | 7 - 21 V (2-5S) |
| Ranging Mode | Measures distance to drone |
| Frequency Range | 5.725 - 5.850 GHz |
| Transmitter Power (EIRP) | FCC: < 30 dBm, CE: < 14 dBm, SRRC: < 20 dBm, MIC: < 25 dBm |
| Interfaces | USB Type-C, MicroSD slot (up to 256 GB), DC5.5×2.1, HDMI output |
| Focal Length | Adjustable from +2 to -6 dptr |
| Field of View (FOV) | 46° |
| Refresh Rate | 1080/100 Hz (supports up to 120 FPS) |
| Screen Size | 0.49 inches |
| SD Card Support | up to 256 GB |
Comfort during use is ensured by adjustable ventilation to reduce fogging, mechanical interpupillary distance (IPD) adjustment in the range of 58–70 mm mechanically and 54–74 mm visually, and focus adjustment from +2 to -6 diopters, so corrective lenses are generally not required.
The goggles support an input voltage of 7–21 V (2–5S), controlled by a power button. Interfaces include USB Type-C for updates and connections, a MicroSD slot for video storage up to 256 GB, DC5.5×2.1 for external power, and an HDMI output for connecting monitors or recording devices.
Package contents:
1 x Walksnail Avatar HD Goggles
4 x Antennas
1 x Power cable
1 x HDMI cable
1 x USB Type-C cable
1 x Protective case or storage box
1 x User manual
1 x Warranty card
The Walksnail Avatar HD model is ideal for pilots transitioning to digital FPV who require high image quality, stable signal transmission, and flight recording capabilities. Thanks to their compactness, adjustability, and a set of four antennas, these goggles are ready for intensive use in racing and freestyle flights, providing convenience, long-lasting performance, and excellent visibility in various conditions.
