FPV Goggles SKYZONE SKY04X Pro OLED 5.8G 48CH — Premium for FPV Immersion

SKY04X PRO — an updated model of FPV goggles from Skyzone, designed for clear and smooth in-flight video. The combination of OLED matrices with 1920×1080 resolution and a 100 FPS refresh rate guarantees high image quality; a 52° field of view provides a wide range of visibility for the most realistic flight experience.

The matte finish body reduces glare and fingerprints, while the ergonomic design, adjustable focus, and wide interpupillary distance range ensure comfort during long sessions. The goggles support 4:3 and 16:9 aspect ratios, making them versatile for various cameras and video formats.

Specifications

• Screen Type: OLED
• Resolution: 1920×1080
• Refresh Rate: 100 FPS
• Field of View (Diagonal): 52°
• Aspect Ratio: 4:3 / 16:9
• Adjustable Focus: -6 to +2
• Interpupillary Distance (IPD): 58–71 mm
• Receiver: 5.8 GHz, 48CH V3.3 Steadyview
• DVR: H.264, 60 FPS
• HDMI IN: 720P 100 FPS
• Input Voltage: 2–6S LiPo
• Head Tracking System: 3-axis accelerometer and 3-axis gyroscope
• Dimensions: 185×75×67 mm
• Weight: 267 g

Package Contents

• SKY04X Pro Goggles
• Steadyview V3.3 Receiver Module
• 2 Faceplates (wide and narrow)
• Velcro Sponge
• Zipper Case
• Power Cable
• Head Tracker Cable
• 2 5.8 GHz 2 dB Antennas
• Video/Audio Cable
• USB-C Cable
• SKY04X Pro User Manual

Special Notes: A fan is installed in the right part of the goggles to cool the OLED panel; due to the presence of the fan, this model does not support quadversity mode, which should be considered when planning the receiver configuration. The included antennas enhance reception stability in various flight conditions, and the built-in DVR allows recording video in H.264 format at up to 60 FPS.

HDMI IN support (720P, 100 FPS) opens up possibilities for connecting external video sources, making the SKY04X Pro convenient for training, competitions, and aerial photography. Powering from 2–6S LiPo batteries provides flexibility in choosing a power source.

Manufacturer: Skyzone

Product Category: Drones & Quadcopters > Drone Components > FPV Goggles

SKY04X PRO are suitable for both beginners and experienced pilots who value high resolution, fast frame rates, and reliable 5.8 GHz reception. The ergonomic design and weight of only 267 g reduce fatigue during long flights, and the ability to adjust focus and IPD allows for individual customization of the goggles for the user.

Inside the kit, you will find all the necessary cables and accessories for a quick start: from power and USB-C cables to spare faceplates and a protective case. The user manual will help you quickly set up the device and start flying.
