Flytex 2807 1300kV Brushless FPV Motor
The Flytex 2807 1300kV motor is a high-performance brushless motor designed specifically for racing and freestyle multicopters. This Flytex branded model combines high power, energy efficiency, and reliability, ensuring quick response to remote commands, stable control, and extended flight times. The standard 2807 frame size and 1300kV rating make this motor an excellent choice for pilots seeking aggressive dynamics combined with control and precision.
Advantages of the Flytex 2807 1300kV Motor
- High Performance: The motor provides maximum thrust and rapid acceleration necessary for aggressive maneuvers and races.
- Energy Efficiency: Optimized internal components reduce energy consumption, allowing for increased overall flight duration without sacrificing dynamics.
- Reliability and Quality: The thrust characteristics and manufacturing materials guarantee durability and stable operation in challenging flight conditions.
- Mounting Versatility: The 2807 size is suitable for a wide range of frames, for both amateur and professional builds.
- Responsive Control: The 1300kV provides quick response to remote commands, smoothness in flips, rolls, and high-speed passes.
The Flytex 2807 1300kV is recommended for racing and freestyle quadcopters where a combination of speed, control, and endurance is crucial. This model allows the pilot to better feel the aircraft in various flight modes, ensuring stability and predictable response to commands.
Below are technical experimental data and motor performance indicators at different voltages and loads. The table contains information on thrust, RPM, power consumption, current, and pulsations, which will help in accurately selecting the speed controller (ESC) and propellers for maximum efficiency.
| U, V | I, A | Thrust | Speed | P,W | Throttle | Toolkit Current | Pulsations | Pulsations |
| 24.0V | 0.94 | 460 | 54000rpm. Prop. 200 | 25 | 20 | 0.95 | 1120 | 75mA/Hr |
| 24V | 1.45A | 800 | 55400rpm. Prop. 200 | 35W | 30 | 1.44A | 1171 | 110mA/Hr |
| 24V | 1.87A | 1000 | 72200rpm. prop. 100 | 46W | 40 | 1.90A | 1204 | 189mA/Hr |
| 24.0V | 2.18A | 1140 | 76600rpm. | 53W | 50 | 2.19A | 1225 | 256mA/Hr |
| 24.0V | 2.45A | 1350 | 80600rpm. Prop. 400 | 60W | 60 | 2.45A | 1243 | 337mA/Hr |
| 24.0V | 2.93A | 1450 | 85400rpm | 70W | 70 | 2.93A | 1264 | 414mA/Hr |
| 24.0V | 3.31A | 1600 | 896000rpm. | 79W | 80 | 3.31A | 1291 | 455mA/Hr |
| 24.0V | 3.86A | 1830 | 95000rpm. | 92W | 90 | 3.86A | 1324 | 500mA/Hr |
| 24.0V | 4.18A | 1960 | 97000rpm. | 98W | 100 | 4.18A | 1342 | 566mA/Hr |
Brand: Flytex
Category (in description): Drones and Quadcopters > Drone Components > Drone Spare Parts > Motors
Category (productType field): Drones and Quadcopters > Motors
If you are selecting a motor for an FPV project, pay attention to the compatibility of the speed controller (ESC) and propellers with the technical parameters provided. Correct selection of the ESC and propeller will maximize efficiency, prevent overheating, and ensure safe operation in peak modes. The Flytex 2807 1300kV is recommended for pilots who value speed, precise control, and component durability.
