3dTech Ground Control Module

The 3dTech Ground Control Module is a stationary, rapidly deployable control station for operating UAVs via fiber optic communication. The device is designed for field use and combines a durable sealed enclosure, autonomous power supply, powerful video and radio components, as well as a set of cables and mounts for quick installation. The module ensures reliable communication, high video quality, and compatibility with modern controllers, making it an optimal solution for inspections, monitoring, search and rescue operations, and commercial missions.

Key Features

• Weight: 1725 g
• Enclosure: sealed (dust and moisture protection)
• Power Battery: 4S2P (autonomous operation without external power source)
• Video Transmitter: 5.8G, 2.5W power (high-quality video stream transmission for pilot and operators)
• Radio Transmitter: ELRS (compatibility with modern controllers)
• Dimensions with mount: 260 mm / 200 mm / 145 mm

Operating Modes

• Direct Control: wired fiber optic connection for stable communication without radio interference at the deployment site
• Remote Control: repeater mode for expanding coverage area and enabling UAV control at a significant distance

Package Contents

• Ground module: 1 pc.
• Mast: 210 cm (for raising the antenna and improving visibility and relay efficiency)
• Video cable: 20 m (for flexible placement of video equipment)
• Control cable: 20 m (for connecting to a remote control or other equipment)
• Mounting system: 1 pc. (for secure module fixation)

Brand: 3dtech. Product type: Ground relay stations. The module is optimized for field tasks where rapid deployment, connection stability, and mobility are crucial. The sealed enclosure protects electronics from dust and moisture, and the 4S2P battery allows autonomous operation in remote conditions without the need for external power.

The 5.8G video transmitter with 2.5W power ensures stable and high-quality video signal transmission, which is critical for the pilot and ground operators during complex tasks. The ELRS radio provides reliable compatibility with modern controllers and enables secure remote control. Dimensions with mount of 260×200×145 mm make the module compact for integration into transport solutions and mounting assemblies, and the 210 cm mast significantly increases the range and efficiency of signal relay.

The kit includes 20 m cables for video and control, allowing the coverage area to be configured without additional wiring and providing flexibility in equipment placement. The module is suitable for infrastructure inspections, territory monitoring, search and rescue operations, and commercial missions where stability, reliability, and rapid system deployment are priorities.

The 3dTech Ground Control Module is a combination of mobility, protection, and professional signal relay capabilities, making it an effective tool for performing tasks of any complexity in field conditions.
