Shifeng SF-220 Mototractor — A Practical Choice for Small and Medium Farms

Model: Shifeng SF-220. Manufacturer: Shifeng. This mototractor combines a reliable design with an affordable price and is intended for a wide range of tasks: plowing, cultivating, soil preparation, cargo transportation, and working with mounted and trailed equipment.

Engine and Basic Specifications

The Shifeng SF-220 is equipped with a single-cylinder, four-stroke engine model 138-2 with a maximum power of 24 hp and a nominal power of 22 hp. The cylinder bore is 115 mm, and the piston stroke is 125 mm. The engine operating speed is rated at 2200 rpm. The fuel tank capacity is 12 L. The cooling system is water-cooled, and the lubrication system is a gear pump. The engine weighs 230 kg, with dimensions of 820 x 530 x 750 mm. Starting is possible via electric starter or manual start (Z-shaped handle).

Transmission, Drive, and PTO

The tractor features a mechanical gearbox with a gear formula of (3+1) × 2 (some sources state 3x2 + 1), allowing a forward speed of up to 30 km/h. The drive from the engine is implemented by a pair of V-belts under constant tension. PTO type: pulley on the flywheel; additionally specified as non-independent 6-spline Ø35 with rectangular splines, 720 rpm. The final transmission is a cylindrical spur gear, external spur gear engagement. The tractor includes a differential lock.

Chassis, Dimensions, and Wheelbase

The wheel formula is 4x2, with a non-adjustable front track of 117 cm (1170 mm) and a rear track of 120 cm. The wheelbase is 140 cm (1400 mm). Ground clearance is 320 mm. The overall dimensions of the tractor are 2815 x 1470 x 1450 mm, and the unit's weight is 908 kg. The front wheels are 4.0" x 14" with a less aggressive tread for better rolling, while the rear wheels are 7.5" x 20" with a high-quality lug tread. The minimum turning radius is 2.2 m.

Brakes, Clutch, Lighting, and Instruments

The braking system is disc-type. The clutch type is dry, twin-disc. The lighting system consists of two headlights with high and low beams, turn signals, and marker lights. There is a horn. The dashboard features a voltmeter, temperature gauge, and oil pressure gauge.

Trailed and Mounted Equipment, Configuration

The Shifeng SF-220 is compatible with major types of trailed and mounted agricultural equipment. Due to the non-adjustable track, adjustment of the position of mounted implements may be necessary. Front and rear ballast weights are available in the standard configuration, and there is a hitch for a trailer. The model is equipped with a differential lock to improve off-road capability and reliability in the field.

Operational Advantages and Sales

The Shifeng SF-220 mototractor is popular among small and medium farms due to its optimal balance of price and capabilities. It is delivered throughout Ukraine; payment options include full payment or purchase on credit. It is recommended to select mounted equipment considering the non-adjustable track and PTO specifications.

Key technical parameters and features:

• Engine: 138-2, single-cylinder, 4-stroke.
• Maximum power: 24 hp, nominal: 22 hp.
• Cylinder bore / piston stroke: 115 mm / 125 mm.
• Rotational speed: 2200 rpm.
• Fuel tank capacity: 12 L.
• Cooling system: water-cooled; lubrication: gear pump.
• Start: electric starter + manual start (Z-shaped handle).
• Gearbox: mechanical, (3+1) × 2; maximum speed up to 30 km/h.
• Drive: pair of V-belts under constant tension.
• PTO type: pulley on flywheel; also non-independent 6-spline Ø35 with rectangular splines, 720 rpm.
• Brakes: disc; clutch: dry, twin-disc.
• Track: front 1170 mm, rear approximately 1200 mm; wheelbase 1400 mm.
• Dimensions: 2815 x 1470 x 1450 mm, weight 908 kg, ground clearance 320 mm.

This description covers all technical and operational features of the Shifeng SF-220 mototractor, which will help in making an informed choice when purchasing or selecting mounted equipment. We also recommend paying attention to other mototractor models: Bulat, Bulat t25, Bulat 120, Bulat 150, Garden Scout, Scout t15, Scout t18, Scout t25, Scout 24, Tractor Fighter, Fighter t15, Fighter t18, Fighter t16, Tractor Forte, Forte t161, Forte t181, Forte t241, Tractor DTZ, DTZ 180, Shifeng 240.
