Foton-Lovol FT504 CNC Mini Tractor — A Reliable Assistant for Your Farm
Model: Foton-Lovol FT504 CNC Mini Tractor. Manufacturer: Foton. Type: Tractors > Mini Tractors. This mini tractor combines high power and versatility: a 50 hp (36.8 kW) four-cylinder diesel engine, an electric starter for easy ignition, 4x4 all-wheel drive, and an independent power take-off (PTO) shaft. The FT504 CNC is ideal for field cultivation, farm work, transportation, and operating with mounted equipment.
Key advantages of the model include a reliable transmission, hydraulic steering, two external hydraulic channels for connecting additional equipment, a dry dual-disc clutch, and air conditioning for comfortable operator work. The robust chassis and optimal dimensions allow the tractor to be operated in various conditions, maintaining maneuverability and stability on the ground.
Technical Specifications
Engine Model | 4-cylinder | |
Number of Cylinders | 4 | |
Diesel Engine Power, hp / kW | 50/36.8 | |
Engine Start Type | electric starter | |
Tractor Traction Force, kN | 10.8 | |
Transmission Type | 4x4 | |
PTO Shaft Type | independent | |
Number of PTO Splines | 8 | |
PTO Speed, rpm | 540/1000 | |
Steering | hydraulic | |
External Hydraulics | two channels | |
Clutch | dry dual-disc | |
Track Width, mm | front 1250, 1320, rear 1220, 1300, 1580 | |
Wheelbase, mm | 1990 | |
Minimum Ground Clearance, mm | 280 | |
Rear Wheel Size | 12.4x28 | |
Front Wheel Size | 8.3x20 | |
Overall Dimensions, mm | length | 4100 |
width | 1700 | |
height | 2700 | |
Number of Gearbox Speeds | (4×3)+(4×3) | |
Air Conditioner | yes | |
The Foton-Lovol FT504 CNC mini tractor offers versatility: the ability to work with a wide range of mounted and trailed equipment thanks to an independent PTO with 8 splines and two operating speeds of 540/1000 rpm. A traction force of 10.8 kN allows for complex tillage operations, while 4x4 all-wheel drive and a ground clearance of 280 mm facilitate work on uneven terrain. The design with a dry dual-disc clutch and robust transmission ensures a long service life under intensive use.
The FT504 CNC is suitable for private farms, agricultural, and municipal work. With air conditioning and an electric starter, the operator benefits from comfort and quick engine start in any weather. Optimal dimensions (4100 mm length, 1700 mm width, 2700 mm height) make the tractor maneuverable both in fields and in confined farmyard spaces.
By choosing the Foton-Lovol FT504 CNC mini tractor, you get a powerful and reliable tool for a wide range of applications, well-balanced in terms of power, hydraulics, and cabin ergonomics. This model features an electric starter, hydraulic steering, two external hydraulic channels, and air conditioning, making it an excellent choice for long and comfortable work.
