The Faighter T-504CRD mini tractor from the Faighter brand is a powerful, versatile mini tractor in the "Tractors > Mini Tractors" category, designed for a wide range of agricultural, municipal, and transport tasks. The T-504CRD model combines 50 hp (29.42 kW) of useful power, 4x4 all-wheel drive, and a reliable 4-stroke KM495BT diesel engine with four cylinders and a displacement of 3170 cm3, providing a nominal traction force of 13.5 kN at a nominal 2400 rpm.
This mini tractor is equipped with an enclosed cabin with air conditioning and heating, ensuring operator comfort in various climatic conditions. The mechanical transmission with reverse and gearbox (mechanical (4+4)x2) make the machine maneuverable and easy to operate, while power steering significantly simplifies control. The clutch is dry, dual-disc; rear differential lock is provided for increased off-road capability; the braking mechanism consists of disc brakes on the rear wheels with mechanical drive and twin pedals.
The Faighter T-504CRD mini tractor is designed for the following tasks:
- Plowing and preparing soil for sowing;
- Sowing, cultivating, and harvesting agricultural crops;
- Mowing and collecting hay;
- Transporting goods and working with mounted and trailed equipment.
Model advantages:
- High power and fuel efficiency: nominal fuel consumption ≤243 g/kWh;
- Reliable KM495BT diesel engine with a long service life;
- Operator comfort and protection thanks to the sealed cabin with air conditioning and heating;
- Ease of control due to power steering and well-designed ergonomics of controls;
- Wide possibilities for aggregation with mounted and trailed equipment, a large 50-liter fuel tank for long work shifts;
- Effective disc brakes on the rear wheels and the ability to lock the differential for challenging working conditions.
Specifications
| Engine power, hp (kW) | 50 (29.42) |
| Wheel formula | 4x4 |
| Engine type | 4 cylinders, KM495BT diesel engine |
| Engine displacement, cm3 | 3170 |
| Nominal fuel consumption g/kWh | ≤243 |
| Nominal engine crankshaft speed rpm | 2400 |
| Nominal traction force kN | 13.5 |
| Gearbox (transmission) | mechanical (4+4)x2 |
| Rear differential lock | yes |
| Clutch | dry, dual-disc |
| Power steering | yes |
| Braking mechanism | on rear wheels, disc, with mechanical drive, twin pedals |
| Power take-off (PTO) shaft speed rpm | 540/1000 |
| Maximum lifting capacity of mounted mechanism, kg | 880 |
| Front wheel track, mm | 1260-1460 |
| Rear wheel track, mm | 1180-1440 |
| Front tire size | 8.3-20 |
| Rear tire size | 12.4-28 |
| Fuel tank capacity L | 50 |
| Overall dimensions (LxWxH), mm | 3350x1890x2650 |
| Structural weight, kg | 2020 |
The Faighter T-504CRD mini tractor is an optimal choice for farms, agricultural enterprises, and private users who need a combination of power, comfort, and versatility. The model provides ease of control, high productivity in field and municipal work, and compatibility with various mounted equipment. For additional technical questions, configurations, or the possibility of installing additional equipment, please contact the seller. Brand: Faighter. Model: T-504CRD. Category: Mini Tractors.
