The DTZ 5354 HPX mini-tractor from the DTZ brand is a modernized all-wheel-drive mini-tractor in the "Mini-tractors" class, designed for a wide range of agricultural, utility, and municipal tasks. The DTZ 5354 HPX model inherited the best features from its predecessor, the 5244 HPX: reinforced transmission components, enhanced operator workstation ergonomics, and reliable parts for long-term intensive use. Below is a complete list of technical specifications and a description of the tractor's key features.

Model Description

The CF3B35T engine with a displacement of 1909 cm3 provides 35 hp of power and operates at a nominal 2300 rpm, delivering sufficient torque at low speeds for heavy tasks: plowing, cultivation, and working with heavy attachments. Three vertically arranged cylinders, a direct-injection diesel fuel system, and an electric starter ensure stable starting and economical fuel consumption. Liquid closed cooling with forced circulation maintains optimal temperature during intensive operation.

Key Advantages

This mini-tractor combines reliability, ease of maintenance, and versatility of application. The reinforced 9+9 mechanical gearbox provides a wide range of speeds for precise selection of operating mode, and the rear splined PTO with 540 rpm allows for connecting various attachments. Hydraulic power steering and a gear pump ensure stable operation under load, and the hitch mechanism can lift up to 415 kg of payload.

• 1. Reinforced transmission: 9 forward and 9 reverse gears for precise selection of operating mode.
• 2. CF3B35T engine, 35 hp, 3 cylinders, displacement 1909 cm3, nominal 2300 rpm.
• 3. Liquid cooling system with forced circulation for reliable operation in various conditions.
• 4. Rear splined PTO 540 rpm for connecting plows, mowers, and other implements.
• 5. Hydraulics with gear pump, lifting capacity 415 kg, with hydraulic outlets.
• 6. Adjustable track: front 1170 or 1370 mm; rear 1200, 1320 or 1400 mm; front tires 6.50-16, rear 11.2-24.
• 7. Minimum ground clearance 350 mm, wheelbase 1610 mm, dimensions 3300x1470x2050 mm, curb weight 1532 kg, fuel tank 32 L.

Configuration and Options

The standard configuration includes a comfortable seat with backrest adjustment and armrests, an automotive-type dashboard with backlighting, projector optics, counterweights, wheel fenders with support handles, a toolbox, and a spare parts kit. Various attachments and towed equipment are additionally available to expand the tractor's functionality.

Application

The DTZ 5354 HPX is suitable for cultivating small and medium-sized land plots, farm work, municipal tasks, sowing, cultivation, cargo transportation, and working with mounted and towed equipment. Its robust design and well-chosen technical solutions allow the tractor to be used as a versatile work unit in various conditions.

Advantages of Purchasing from Flash Army Online Store

The Flash Army online store is an official representative of DTZ in Ukraine and offers favorable terms: in-house delivery, payment upon receipt, the possibility of purchasing on credit or in installments, as well as a wide selection of mounted and towed equipment. The catalog features over 300 models of mini-tractors from leading manufacturers.

Brand: DTZ. Category: Tractors > Mini-tractors. Model: DTZ 5354 HPX.
