RunCam Split-H Camera with HDMI Output and SONY Sensor (5MP)

The RunCam Split-H camera is a modern solution for drones and FPV flights, combining high-quality aerial photography and real-time image transmission. Thanks to the SONY (5MP) sensor, the device provides clear frame detail, while 1080P video resolution at 60FPS ensures smooth and high-quality video. A wide 94° field of view allows for capturing more of the scene during flight, which is important for both professional operators and enthusiasts.

The Split-H supports 1080P HDMI output at 60Hz for connection to a display or video transmitter (VTX), allowing for real-time, lag-free flight control. A high-performance video processing chip ensures simultaneous MP4 video recording and HDMI transmission without frame loss. The built-in microphone allows for audio recording during shooting. The camera is lightweight and compact — weighing only 22g, which makes integration into drone designs simple and without significant increase in device mass.

The device is compatible with memory cards up to 128GB (U3 class recommended) and operates on power sources in the 5-20V range, ensuring compatibility with most drone power systems. Camera mounting is simplified thanks to standard mounting holes, making installation on various frames and brackets easy. The Split-H also supports PWM for remote control, adding flexibility in setup and integration.

Key Features

• Model: Split-H
• Manufacturer: RunCam
• Category: Drones & Quadcopters > Cameras
• Image Sensor: SONY (5MP)
• Field of View: 94°
• Video Resolution: 1080P at 60FPS
• Video File Format: MP4
• HDMI Output Format: 1080P at 60Hz
• Max SD Card Capacity: 128GB (U3 recommended)
• Power Range: 5-20V
• Lens Module Size: 19x19 mm
• Mounting Hole Spacing: 26.5x30.5 mm
• Board Size: 32x37 mm
• Operating Current: 540mA@5V / 365mA@7.4V / 225mA@12V
• Weight: 22 g
• Support: PWM for remote control

Advantages and Compatibility

The RunCam Split-H is ideal for aerial photography, FPV racing, and flight recording due to its combination of compactness, light weight, and professional technical specifications. The real-time HDMI output allows connecting the camera to a monitor or transmitter without additional converters. Support for memory cards up to 128GB and 5-20V power make the camera compatible with a wide range of platforms. Thanks to standard mounting holes, installation is quick and reliable.

The RunCam Split-H is the choice for those who value video quality, reliability, and ease of integration into a drone. This camera combines professional shooting capabilities with the functionality required for modern multicopters.
