PRAMAC GSW22Y Diesel Generator (15.2 kW)
Brand: PRAMAC. This reliable diesel generator is designed to provide energy independence for domestic use, construction, and commercial applications. The PRAMAC GSW22Y model combines power, efficiency, and durability, making it an excellent choice for those who require stable three-phase power with a voltage of 400/230V.
Key advantages at a glance:
- High peak power of 15.22 kW and continuous power of 14.45 kW ensure stable operation of electrical equipment under load.
- Yanmar 4TNV88-BGPGE engine — 4-cylinder, four-stroke with water cooling, 2190 cm3 displacement, guarantees reliable mechanics and long service life.
- Electric starter for convenient start-up in any conditions.
- 68 L fuel tank allows for long operation without frequent refueling; fuel consumption at 100% load is 5.05 L/h, indicating a good balance of power and efficiency.
- Mecc Alte generator, 3-phase, with a nominal power factor of 0.8 cos φ and a frequency of 50 Hz, provides quality power for a wide range of consumers.
This model also features well-thought-out technical specifications: insulation class H for increased thermal resistance, IP21 protection rating suitable for operation in protected environments, and a noise level of 63 dB, making the generator relatively quiet in its class. The unit's dimensions are 1800x850x1260 mm with a weight of 670 kg, which is important to consider when planning installation and transportation. Brand country: Italy.
The PRAMAC GSW22Y is ideally suited for applications requiring stable three-phase power: both as backup power for businesses and for continuous use on construction sites or in autonomous systems. The comprehensive combination of the Yanmar engine and Mecc Alte generator unit ensures efficient operation under load and reliability in intensive operating conditions.
Technical Specifications
Below is the official table of technical parameters for easy reference:
| Voltage: | 400/230V |
| Engine type: | 4-cylinder, four-stroke, water-cooled |
| Engine model: | Yanmar 4TNV88-BGPGE |
| Engine displacement: | 2190 cm3 |
| Start-up: | Electric starter |
| Fuel tank capacity: | 68 L |
| Peak power: | 15.22 kW |
| Continuous power: | 14.45 kW |
| Generator type: | 3-phase, Mecc Alte |
| Nominal power factor: | 0.8 cos φ |
| Frequency: | 50 Hz |
| Noise level: | 63 dB |
| Fuel consumption (100% load): | 5.05 L/h |
| Insulation class: | H |
| Protection rating: | IP21 |
| Dimensions, LxWxH: | 1800x850x1260 mm |
| Weight: | 670 kg |
| Brand country: | Italy |
If you need a powerful and reliable unit for autonomous or backup power — the PRAMAC GSW22Y will be an excellent solution. Contact specialists for selection of optimal configuration, installation, and subsequent service maintenance.
