RUSH Max Solo 5.8G 25/500/1000/2500mW Video Transmitter — Ultra-Powerful VTX for Professional FPV Flight
The RUSH Max Solo 5.8G — a high-performance video transmitter (VTX) designed for pilots who demand maximum range and reliability in video communication. This compact module combines low weight and small dimensions with a powerful 25/500/1000/2500 mW output, making it an ideal choice for both racing quadcopters and long-range flights. The RUSH Max Solo ensures stable transmission and high image quality even in challenging conditions with interference.
Key Advantages
RUSH Max Solo stands out with a maximum power level of up to 2500 mW, a wide input voltage range for compatibility with various onboard systems, and versatile integration into different drone designs. A high-quality AGC microphone is built into the housing, and the transmitter also supports audio input, allowing sound to be transmitted along with video during flight — this is important for FPV filming, live broadcasts, and other tasks where audio information is needed.
Flexible Settings
The transmitter offers 48 transmission channels and a set of power modes: PIT/25/400/800/MAX mW, while the specifications also list 25/500/1000/2500 mW levels. This variability allows for precise adjustment of output power to suit competition or flight conditions, reducing interference in dense networks while achieving maximum range where necessary.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | Rush Max Solo 5.8G |
| Device Type | Video Transmitter (VTX) |
| Input Voltage | 7-36 V DC |
| Output Voltage | 5V/1A (600 mA) |
| Channels | 48 channels |
| Power Modes | PIT/25/400/800/MAX mW (25/500/1000/2500 mW also mentioned in title) |
| Maximum Power | 2500 mW |
| Audio | Audio input support |
| Microphone | Built-in high-quality AGC microphone |
| Dimensions | 37 x 24 x 6.7 mm |
| Weight | 12 g (without cable) |
Frequency Table
| CHANNEL | Band A | Band B | Band E | Band F | Race Band | Low Band |
|---|---|---|---|---|---|---|
| 1 | 5865 | 5733 | 5705 | 5740 | 5658 | 5362 |
| 2 | 5845 | 5752 | 5685 | 5760 | 5695 | 5399 |
| 3 | 5825 | 5771 | 5665 | 5780 | 5732 | 5436 |
| 4 | 5805 | 5790 | 5645 | 5800 | 5769 | 5473 |
| 5 | 5785 | 5809 | 5885 | 5820 | 5806 | 5510 |
| 6 | 5765 | 5828 | 5905 | 5840 | 5843 | 5547 |
| 7 | 5745 | 5847 | 5925 | 5860 | 5880 | 5584 |
| 8 | 5725 | 5866 | 5945 | 5880 | 5917 | 5621 |
Who It's For
This VTX will be useful for pilots seeking high-quality and long-range video communication: professional drone racing pilots, long-range flight enthusiasts, FPV filming operators in challenging conditions, and racing drone owners looking for a compact and powerful solution. Its compact size and low weight make it easy to integrate into most platforms without significantly affecting mass and aerodynamics.
Package Contents
Included in the package:
- 1x Rush FPV Solo Tank 25-1000 mW 5.8 GHz VTX with Smart Audio – MMCX
- 1x 90° MMCX Dipole Antenna
- 1x MMCX to SMA Pigtail
Additional information: manufacturer / country of origin — China. Product category: Drones & Quadcopters > Drone Components > Drone Parts > Transmitters.
The RUSH Max Solo 5.8G combines professional features, flexible settings, and compactness, making it an excellent choice for FPV pilots who prioritize signal quality and transmission range.
