Foton TB-504: Powerful Mini Tractor with Cabin for All-Season Work
The Foton TB-504 mini tractor with cabin is a versatile solution for private farms, agricultural enterprises, or municipal services. Manufacturer: Foton. Category: Mini Tractors. The 2018 model combines reliable Chinese components and high performance: a 4-cylinder diesel engine with water cooling ensures stable operation under load, and its 50 hp (36.8 kW) power allows for efficient execution of a wide range of agricultural and municipal tasks.
Key advantages of the model include: a heated cabin for working in cold weather and during precipitation, an electric starter for reliable ignition in freezing temperatures, 4x4 all-wheel drive for working on difficult terrain, and power steering for operator convenience. Thanks to the standard three-point hitch system and an independent PTO with speeds of 540/1000 rpm, the TB-504 is compatible with a wide range of attachments.
Engine: 4-cylinder diesel with water cooling.
Power: 50 hp / 36.8 kW.
Starting: Electric starter.
Drive: 4x4 (all-wheel drive).
Steering: Hydraulic with power assist.
PTO: Independent, 540/1000 rpm.
Wheels: Front 8.3x20, Rear 12.4x28.
This mini tractor is suitable for both field work and tasks on homestead plots or in the municipal sector. The heated cabin ensures operator comfort, while thoughtful ergonomics and quality assembly make operation less tiring even during long shifts. The Foton TB-504 offers a good price-to-quality ratio and often surpasses similar models in its class in terms of technical specifications.
Price of Foton TB-504 with Cabin, Free Delivery in Ukraine
Flash Army offers the Foton TB-504 at a competitive price with free delivery across Ukraine, covered by our store. We provide professional technical support and consultations before purchase — contact us using the details on our website. Upgrade your equipment fleet now and get a reliable mini tractor for a wide range of tasks.
Technical Specifications
Engine model | 4-cylinder | |
Number of cylinders | 4 | |
Diesel engine power, hp / kW | 50/36.8 | |
Engine start type | electric starter | |
Tractor traction force, kN | 10.8 | |
Transmission type | 4x4 | |
PTO shaft type | independent | |
Number of PTO splines | 8 | |
PTO speed, rpm | 540/1000 | |
Steering | hydraulic | |
External hydraulics | two channels | |
Clutch | dry dual-disc | |
Track width, mm | front 1250, 1320, rear 1220, 1300, 1580 | |
Wheelbase, mm | 2000 | |
Minimum ground clearance, mm | 360 | |
Rear wheel size | 12.4x28 | |
Front wheel size | 8.3x20 | |
Overall dimensions, mm | length | 4070 |
width | 1670 | |
height | 2700 | |
Number of transmission speeds | (4×3)+(4×3) | |
Air conditioning | no | |
The technical specifications list all key parameters for selecting attachments, choosing the wheel formula, and organizing service maintenance. The package includes an independent power take-off shaft, two external hydraulic channels, and a dry dual-disc clutch — these are important factors for durable operation under intense loads.
