KATA KE 904 Tractor — Powerful Universal Mototractor from KATA

The KATA KE 904 model is a reliable mototractor from the KATA brand, designed for a wide range of agricultural, municipal, and transport tasks. This tractor combines a high-resource diesel engine, all-wheel drive, and well-engineered mechanics, making it an effective solution for medium and large farms, municipal enterprises, and owners who value versatility and durability.

Key Technical Specifications

Engine: The diesel, 4-stroke YTO YD4EZ90C1 engine with 4 vertically arranged cylinders provides stable traction. The engine power is 90 hp (66.2 kW), with a displacement of — 4080 cm3. The starting system is an electric starter. Cooling is liquid, closed, with forced circulation of coolant, ensuring stable operation in various climatic conditions. The nominal engine fuel consumption is ≤225 g/kWh, which ensures economical operation under load.

Transmission and Chassis: The wheel formula is — 4x4 with rear differential lock, which increases проходимость on difficult terrain. The gearbox is — 12+12 speeds. The clutch is — dry 2-disc constantly closed type; the main drive is — direct. The nominal traction force of the tractor is — 22 kN.

Steering and Braking: Steering is — hydraulic; brakes are located on the secondary shaft of the gearbox, designed as brake drums. The power take-off (PTO) shaft is — rear, splined, with speeds of 540 / 1000 rpm.

Hydraulics and Attachments: The hydraulic system pump type is — gear pump (NSH) for implement drive and NSH for power steering operation. The number of hydraulic outputs is — 2. The lifting capacity of the hitch is — 2500 kg, allowing the use of a wide range of mounted and trailed equipment. A trailer connector (socket) and compressor are available for ease of use.

Tires and Clearance: Wheel track — front 1275-1355 mm, rear 1270-1480 mm; tire size — front 8.3-24, rear 14.9-30. The tractor's ground clearance is — 535 mm, ensuring operation on uneven terrain. Dimensions LWH — 3970x1710x2615 mm, curb weight — 3300 kg.

Configuration and Additional Options: Electric starter for quick engine start, trailer connector, compressor, ability to connect various attachments thanks to a powerful hydraulic system and advanced transmission.

Below is a complete list of technical parameters for easy reference:

Practical Application

The KATA KE 904 is effective for plowing and cultivation, performing sowing and harvesting operations with mounted equipment, towing trailers, and for transport and municipal work. The 4x4 all-wheel drive, differential lock, and high ground clearance allow it to work on difficult soils and uneven terrain, while its 2500 kg lifting capacity and advanced hydraulic system open up possibilities for a wide range of mounted tools.

This tractor is optimal for medium and large farms, municipal enterprises, and users looking for a powerful, economical, and functional 90 hp mototractor.

For consultation on configuration selection or ordering, please contact our managers. Brand: KATA. Product category: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mototractors.
