Heaveant Parabolic Throw Device for Drones

The professional Heaveant Parabolic Throw Device is designed for reliable integration on drones, multicopters, helicopters, and small aircraft. Manufacturer: China. The kit combines a lightweight 7075 aluminum alloy construction, a servo-driven control system, and reinforced mechanics, making it an optimal solution for lifting and dropping loads in the 4-6 kg range.

Product Advantages

• Reinforced version, capable of lifting and dropping 4-6 kg of payload: optimal strength-to-weight ratio for delivery or emergency drop tasks.
• Automatic flight system | Servo drive | Material: 7075 aluminum alloy: high rigidity and corrosion resistance with minimal mass for long-term operation.
• Stability and shock protection: double ball bearing mechanism ensures smooth operation, resistance to mechanical loads, and long service life.
• ON/OFF controlled by servo drive: precise opening/closing of the mechanism via a single remote control channel for safe payload release.
• Compatible with standard MG995 / MG946R / MG996R servos: adapted for popular models for quick integration into your project.

Note

• The MG996R servo is recommended for the kit or for compatibility.
• Remember to adjust the servo's operating schedule for precise positioning and synchronization with the remote control.
• Total system weight — approximately 87 g.
• Ejector operating voltage: 5 V.
• It is recommended to use a separate UBEC to power the ejector. Do not connect power directly from the receiver to avoid affecting voltage fluctuations during flight.

Lightweight Aluminum Payload Release System for Drones

• Material: 7075 aluminum alloy — combining strength and low weight.
• High strength, low weight: the design allows the system to be used in field conditions with minimal impact on the overall mass of the flying platform.
• Reinforced version: designed for dropping payloads weighing 4-6 kg.
• Compatibility: suitable for helicopters, multicopters, airplanes, robots, and other devices.
• ON/OFF control via servo drive: controlled by a single channel of the remote control for easy integration.
• Meets standard servo sizes: compatible with 996, S3003, 995, 946, 3001, and other standard servo sizes.

MG996R Metal Servo

Features:

• Gear type: metal and plastic gears for increased reliability.
• Torque: 12 kg/cm at 6 V — sufficient to open the mechanism with a payload.
• Power supply: via external adapter for stable operation under load.
• Servo operating voltage: 4.8 – 7.2 V.
• Temperature range: 0°C to 55°C.
• Operating speed: 0.17 s / 60° at 4.8 V (no load), 0.13 s / 60° at 6.0 V (no load).
• Compatibility: suitable for most standard receiver connectors: Futaba, Hitec, Sanwa, GWS, etc.
• Stability and shock protection: double ball bearing ensures reliable operation; connecting wire length 300 mm.
• Ideal for use in cargo models, boats, racing cars, helicopters, and airplanes.

Specifications:

• Connecting wire length (servo): 300 mm.
• Servo net weight: 61 g.
• Servo color: black.

The Heaveant Parabolic Throw Device is a combination of reliable mechanics, proven servos, and lightweight aluminum alloy for long-term operation. The product is suitable for a wide range of applications: from civilian delivery and search and rescue operations to amateur and professional drone projects. Product type: Drones & Quadcopters > Drone Components > Drone Accessories.
